CPM60 1.1 kW high flow water pressure pump, 350 L/min

CPM60 high flow pump with cast iron body, single-phase motor

CPM60 High Flow Water Pressure Pump, 1.1 kW, 350 L/min, 25 m Head

Name: CPM60 High Flow Water Pressure Pump, 1.1 kW, 350 L/min, 25 m Head
SKU: KMN-WATR-0388
Price: 3842.00 ZAR
Availability: InStock

SKU KMN-WATR-0388

A 1.1 kW high flow pressure pump moving up to 350 L/min at 25 m head, sold as the pump only and delivered from Polokwane.

R3 842,00

High flow: up to 350 L/min (21 m³/h)
1.1 kW, 230 V single-phase
Up to 25 m head
Cast iron body, brass impeller

Delivered by our own trucks in 1 to 3 days. R550 / R950 / R1,450 by order weight. FREE on orders of R20,000 or more with code KH027. Delivery details

Specifications

Model	CPM60 high flow pump, pump only
Flow rate	Up to 350 L/min (21 m³/h)
Max head	25 m
Duty point	200 L/min at 19 m
Voltage / phase	230 V, 50 Hz, single-phase
Power	1.1 kW
Inlet / outlet	On request
Suction lift	Max 7 m
Self-priming	No, prime the pump before first start
Duty cycle	On request
Fluid compatibility	Clean water without abrasives, max 40 °C
Pump body / impeller	Cast iron / brass
Motor shaft / seal	Stainless steel 304 / ceramic-graphite
Motor protection	Thermal overload, insulation class B, IP44
Net weight	14 kg
Shipping weight	15.5 kg
Dimensions	400 × 230 × 290 mm

Description

Overview

The CPM60 is a 1.1 kW single-stage pump that moves up to 350 L/min (21 m³/h) at a maximum head of 25 m. That is almost three times the flow of the 1.1 kW CPM170, traded for lower head, so it is the one to choose for filling tanks, supplying sprinklers and shifting bulk water rather than pushing it up a building. This listing is the pump only.

The performance table gives 22.8 m at 50 L/min, 21.8 m at 100 L/min, 20.7 m at 150 L/min, 19 m at 200 L/min, 16 m at 250 L/min, 12.9 m at 300 L/min and 4.4 m at 350 L/min. Pick a pump whose head at the flow you need is higher than your total head, which is the height you lift the water plus pipe friction. The body is cast iron, the impeller is brass, the shaft is stainless steel 304 and the seal is ceramic-graphite. The motor is single-phase 230 V with a capacitor and thermal overload protector, insulation class B, IP44. For pressure control, see the CPM60 combo with pressure switch. If you need more head at lower flow, look at the CPM170 booster pump. See the whole booster pump range too.

Key features

350 L/min maximum flow for fast tank filling
25 m maximum head, steady through the mid range
Cast iron body and brass impeller
Suction lift up to 7 m
Clean water duty up to 40 °C
Capacitor motor with thermal overload protection

Where it works

Typical jobs are filling a 10,000 L farm tank in the Free State, running sprinklers on a Limpopo citrus block, moving water between dams and tanks near Polokwane, and supplying wash-down points at depots. It needs clean water without abrasive particles and must stand under a vented cover, away from rain and spray.

What’s in the box

CPM60 high flow pump, 1.1 kW

Delivery and warranty

Kamano delivers with its own trucks from Polokwane to all nine provinces in 1 to 3 days, including Polokwane, Bloemfontein, Welkom, Tzaneen, Johannesburg and Klerksdorp. Shipping weight is about 15.5 kg, in the up to 30 kg band at R550, and orders of R20,000 or more (VAT incl.) ship free. Ask us for the warranty terms on this model.

Questions about this product

How is the CPM60 different from the CPM170?

Both have 1.1 kW motors. The CPM60 moves up to 350 L/min at 25 m head, while the CPM170 moves up to 120 L/min at 44 m. Choose the CPM60 for volume, such as tank filling, and the CPM170 for pressure.

Can I use it for irrigation?

Yes, for clean water. At 200 L/min it still gives 19 m, enough for many sprinkler zones. Check the head needed at your sprinkler flow and add pipe friction to be sure.

Do you deliver to Tzaneen?

Yes. Our own trucks deliver to Tzaneen and all nine provinces in 1 to 3 days from Polokwane. At about 15.5 kg this pump is in the up to 30 kg band at R550, and orders of R20,000 or more (VAT incl.) ship free.
