2CPM25 2.2 kW end-suction booster water pump with controller

2CPM25 Booster Water Pump with Controller, 2.2 kW, 55 m

Name: 2CPM25 Booster Water Pump with Controller, 2.2 kW, 55 m
SKU: KMN-PUMP-0328
Price: 6396.00 ZAR
Availability: InStock

SKU KMN-PUMP-0328

A 2.2 kW end-suction booster pump with controller, 55 m head and 150 L/min, for pressure boosting at homes, farms and fire-fighting sets, delivered from Polokwane.

R6 396,00

2.2 kW, 230 V booster pump with controller
Up to 55 m head and 150 L/min, 8 bar working pressure
Overload protection, quiet and maintenance-free
1 1/2 in x 1 in pipe connections

Delivered by our own trucks in 1 to 3 days. R550 / R950 / R1,450 by order weight. FREE on orders of R20,000 or more with code KH027. Delivery details

Specifications

Pump type	End-suction booster pump with controller
Flow rate	150 L/min maximum
Max head / pressure	55 m head; 8 bar maximum operating pressure
Voltage / phase	230 V, 50 Hz, single-phase
Power	2.2 kW input
Inlet / outlet	1 1/2 in x 1 in
Self-priming	On request
Duty cycle	On request
Fluid compatibility	Clean water without abrasive particles; liquids not chemically aggressive to the pump materials
Protection	Overload protection
Installation	Under a vented cover, protected from rain and spray
Model	2CPM25-1
Net weight	20 kg
Shipping weight	22 kg
Dimensions	518 x 278 x 345 mm

Description

Overview

The 2CPM25 is a 2.2 kW, 230 V end-suction booster pump supplied with a controller, built to raise water pressure from a tank, municipal supply or storage dam. It reaches 55 m of head, 150 litres a minute and 8 bar maximum operating pressure.

The supplier recommends it for clean water without abrasive particles, and for liquids that are not chemically aggressive to the pump materials. It gives high head in a compact housing with low noise, and overload protection guards the motor. Install it under a vented cover, out of rain and spray. For lower-duty supply see the 0.75 kW jet pump, or browse the pumps range.

Key features

2.2 kW motor on 230 V, 50 Hz
Maximum head of 55 m and flow of 150 L/min
Maximum operating pressure of 8 bar
Controller included for automatic pressure operation
Overload protection
Compact, low-noise, maintenance-free design
1 1/2 in x 1 in pipe connections

Where it works

Use it to lift pressure from a tank to a house on a Limpopo farm, feed overhead sprinklers on a Western Cape vineyard, boost mains pressure in Gauteng flats and offices, or increase pressure for fire-fighting sets. It must stay dry, so mount it in a pump room or under a vented cover. A petrol clear water pump fills the supply tank when power is off during load-shedding.

What’s in the box

1 x 2CPM25 booster water pump with controller

Delivery and warranty

Kamano delivers with its own trucks from Polokwane to all nine provinces in 1 to 3 days, including Johannesburg, Cape Town, Polokwane, Bloemfontein, Kimberley and Mbombela. Shipping weight is about 22 kg. Delivery is charged by total order weight: up to 30 kg R550, 30 to 60 kg R950, 60 to 100 kg R1,450, and over 100 kg on quotation. Orders of R20,000 or more (VAT incl.) ship free. Ask us for the warranty terms on this model.

Questions about this product

Can I use it to boost mains water pressure?

Yes, boosting pressure from a tank or supply line is what the 2CPM25 is recommended for, including pressure boosting for fire-fighting sets. Make sure the supply can feed up to 150 L/min and that your pipework is rated for 8 bar. Ask us if you need help sizing the installation.

Can it stand outside in the rain?

No. The supplier states it must be installed under a vented cover and protected from rain and water spray. Put it in a pump room, a ventilated shed or a purpose-built cover. Keeping it dry and well ventilated also helps the motor stay cool.

What liquids can it pump?

Clean water without abrasive particles, and liquids that are not chemically aggressive to the pump materials. It is not for sand-laden bore water, slurry or chemicals. Fit a filter on the suction side if your water carries grit.

Do you deliver to Cape Town?

Yes. We deliver with our own trucks from Polokwane to Cape Town and the rest of South Africa in 1 to 3 days. At about 22 kg this pump is in the up to 30 kg band, so delivery is R550, and orders of R20,000 or more ship free.

Nationwide delivery from Polokwane

Delivered to all nine provinces in 1 to 3 days

We deliver the 2CPM25 Booster Water Pump with Controller, 2.2 kW, 55 m with our own trucks to Johannesburg, Pretoria, Cape Town, Durban, Gqeberha, Bloemfontein, Polokwane, Mbombela, Upington, Kimberley, Rustenburg, Thohoyandou, Secunda and Tzaneen, and to farms, mines and sites in between. This item ships in the R550 delivery band (up to 30 kg). Orders of R20,000 or more deliver free with code KH027.
