0.6 kW Polypropylene Self-Priming Pump, 40 L/min, 36 m Head

Name: 0.6 kW Polypropylene Self-Priming Pump, 40 L/min, 36 m Head
SKU: KMN-WATR-0403
Price: 2136.00 ZAR
Availability: InStock

SKU KMN-WATR-0403

A 0.6 kW polypropylene self-priming pump for clean water transfer and garden supply, delivered by Kamano to all nine provinces.

R2 136,00

Self-priming with up to 7 m suction lift
Polypropylene body with stainless steel 304 shaft
40 L/min (2.4 m3/h) at up to 36 m head
230 V single-phase motor with thermal overload protection

Delivered by our own trucks in 1 to 3 days. R550 / R950 / R1,450 by order weight. FREE on orders of R20,000 or more with code KH027. Delivery details

Specifications

Flow rate	40 L/min (2.4 m3/h) maximum
Max head / pressure	36 m maximum
Voltage / phase	230 V, 50 Hz, single-phase, with capacitor
Power	0.6 kW
Inlet / outlet	On request
Self-priming	Yes, suction lift up to 7 m
Duty cycle	On request
Fluid compatibility	Clean water up to 40 degrees C, ambient up to 40 degrees C
Construction	Polypropylene body, Noryl impeller, stainless steel 304 shaft, ceramic-graphite seal
Motor protection	Thermal overload, Class B insulation, IP44
Net weight	6 kg
Shipping weight	7 kg
Dimensions	330 × 150 × 230 mm

Description

Overview

This 0.6 kW polypropylene self-priming pump moves up to 40 L/min (2.4 m3/h) of clean water against a head of up to 36 m, and it can pull water from as deep as 7 m below the pump. The body is polypropylene with a Noryl impeller, a stainless steel 304 motor shaft and a ceramic-graphite mechanical seal. The 230 V single-phase motor has a capacitor, thermal overload protection, Class B insulation and IP44 protection, so keep it under a vented cover away from rain.

Key features

Self-priming, with suction lift up to 7 m
Polypropylene pump body that does not rust
Noryl impeller and stainless steel 304 motor shaft
Ceramic-graphite mechanical seal
230 V, 50 Hz single-phase motor with capacitor and thermal overload protection
Handles liquid and ambient temperatures up to 40 degrees C

Where it works

It is a sensible pump for garden irrigation, topping up a header tank, and moving clean water from a storage tank or shallow source to the taps on a smallholding. On Limpopo farms and Western Cape lifestyle plots, a pump this size runs sprinklers and a few outlets at a time. Do not use it for abrasive or dirty water. When you need more flow or pressure, step up to the 0.8 kW polypropylene pump or the 63 L/min polypropylene pump, or browse all water booster pumps.

What’s in the box

0.6 kW polypropylene self-priming pump with 230 V motor

Sizing tip

Add your lift from the water level to the highest outlet to the friction in the pipe run, and pick a pump whose head at your required flow is above that total. If you are unsure, send us the layout and we will check it with you.

Delivery and warranty

Kamano delivers with its own trucks from Polokwane to all nine provinces in 1 to 3 days, including Polokwane, Johannesburg, Pretoria, Mbombela, Tzaneen and Rustenburg. The shipping weight is 7 kg, so it sits in the up to 30 kg delivery band at R550. Orders of R20,000 or more (VAT incl.) qualify for free delivery. Ask us for the warranty terms on this model.

Questions about this product

How high can the 0.6 kW pump lift water?

It can draw water from up to 7 m below the pump (suction lift), and it delivers up to 36 m of head at low flow. Real height is less once you count pipe friction and the flow you want, so choose it for the flow you need at your total head.

Is this pump safe to leave outside in the rain?

No. The motor is IP44, which protects against splashes, but the pump should be installed under a vented cover and kept away from rain and water spray. A simple pump cover or small pump room does the job. Keep the area ventilated so the motor stays cool.

How much is delivery to Tzaneen?

The pump ships at about 7 kg, so it falls in the up to 30 kg band at R550 (VAT incl.). Orders of R20,000 or more ship free. Our own trucks deliver from Polokwane to Tzaneen, and the rest of the country, in 1 to 3 days.
