1.1 kW Smart VSD Booster Pump, Wi-Fi, 1¼” Ports, RUC-1100
SKU KMN-WATR-0207
The RUC-1100 is a 1.1 kW smart variable speed booster pump with Wi-Fi app control and 1¼" ports, for larger homes and estates, delivered across South Africa.
R7 370,06
- Higher flow than the RUC-750: up to 10.5 m³/h at 60 m head
- Permanent magnet motor and drive cut running costs against fixed-speed pumps
- Wi-Fi monitoring and pressure setting through the Smart Life app
- 1¼” inlet and outlet, IP55, stainless steel 304 pump parts
Delivered by our own trucks in 1 to 3 days. R550 / R950 / R1,450 by order weight. FREE on orders of R20,000 or more with code KH027. Delivery details
Specifications
| Flow rate | Rated 6 m³/h, max 10.5 m³/h |
|---|---|
| Max head / pressure | Rated and max 60 m head (supplier also quotes 31 m, confirm for your duty) |
| Voltage / phase | 220 to 240 V, single phase, 50 Hz |
| Power | 1.1 kW (1100 W), PMSM motor |
| Inlet / outlet | 1¼" × 1¼" |
| Self-priming | Not stated by supplier |
| Duty cycle | On request |
| Fluid compatibility | Clean water, max 40 °C |
| Max motor speed | 5200 r/min |
| Pump material | Stainless steel 304 |
| Protection / insulation | IP55, insulation class F |
| Connectivity | Wi-Fi via Smart Life app |
| Net weight | 11 kg |
| Shipping weight | 12 kg |
| Dimensions | On request |
Description
Overview
The RUC-1100 is a 1.1 kW smart booster pump that holds pressure constant by varying motor speed, and it is the higher-flow model of the RUC range with 1¼” ports and up to 10.5 m³/h. It suits homes and small estates where the 0.75 kW unit would be pushed.
The permanent magnet motor and variable frequency drive are built into one unit. Connect it to the free Smart Life app to watch pressure, start or stop the pump and change the target pressure remotely. If you only need a smaller motor, the 0.75 kW smart VSD booster pump covers lighter duty. More options are in our booster pumps range.
Key features
- 1.1 kW permanent magnet synchronous motor, IE4/IE5 efficiency class
- Rated 6 m³/h at 60 m head, maximum 10.5 m³/h
- Smart Life app control, and the pump keeps running on its stored settings without Wi-Fi
- Pump Link Mode links two pumps with alternating starts and back-up
- IP55 protection, insulation class F, stainless steel 304 pump parts
- 1¼” inlet and outlet, single phase 220 to 240 V
Where it works
Fit it to a larger family home, a block of flats or a lodge where several bathrooms and a garden line run at once. On a farm in Limpopo or the Free State it can lift pressure from a header tank to a farmhouse, workers’ housing or a small wash bay. Because the drive slows down at low demand, it is easier on your inverter during load-shedding than a fixed-speed pump of the same size. For a pre-assembled option with a storage tank, see the 1000 L slim tank combo with 1.1 kW monoblock pump.
What’s in the box
- 1.1 kW RUC-1100 smart VSD booster pump
Delivery and warranty
Kamano delivers with its own trucks from Polokwane to all nine provinces in 1 to 3 days. Shipping weight is 12 kg, which is up to 30 kg, so delivery is R550. Orders of R20,000 or more (VAT incl.) ship free. Ask us for the warranty terms on this model.
Questions about this product
Should I buy the RUC-750 or the RUC-1100?
Choose the RUC-1100 for more flow and bigger ports: up to 10.5 m³/h on 1¼" connections, against 5.5 m³/h on 1" for the RUC-750. If you have one bathroom and a few taps the 0.75 kW is usually enough. Several bathrooms plus irrigation at once point to the 1.1 kW.
How much does delivery cost for the RUC-1100?
At 12 kg shipping weight it sits in the up to 30 kg band, so delivery is R550, and it is free on orders of R20,000 or more (VAT incl.). We deliver with our own trucks from Polokwane to all nine provinces, normally in 1 to 3 days, including farms and sites outside town.
What is the head rating on this pump?
The supplier's pump specification lists 60 m for both rated and maximum head, while another supplier note mentions 31 m. We have kept both visible on the spec table. Tell us your lift, pipe length and flow before you order and we will confirm the RUC-1100 suits the duty.
Can I control it from my phone?
Yes. Pair it with the free Smart Life app on Android or iOS to see pressure, start and stop the pump, change target pressure and view power use. You need Wi-Fi in range of the pump. If the network is down, the pump keeps running with the settings stored on the unit.
