CP80 high-flow booster pump, 2.2 kW 380 V, up to 400 L/min

CP80 water pressure pump cast iron body with 2" ports

2.2 kW High-Flow Booster Pump, 380 V, 400 L/min, 2″ Ports, CP80

Name: 2.2 kW High-Flow Booster Pump, 380 V, 400 L/min, 2" Ports, CP80
SKU: KMN-WATR-0383
Price: 6160.00 ZAR
Availability: InStock

SKU KMN-WATR-0383

A 2.2 kW three-phase high-flow pump with 2 inch ports and 30 m head, moving up to 400 L/min for irrigation and transfer across South Africa.

R6 160,00

Up to 400 L/min (24 m³/h), 30 m shut-off head
2.2 kW motor, 380 V three-phase
2″ inlet and outlet
Duty point: 200 L/min at 22 m

Delivered by our own trucks in 1 to 3 days. R550 / R950 / R1,450 by order weight. FREE on orders of R20,000 or more with code KH027. Delivery details

Specifications

Model	CP80 single-stage high-flow
Flow rate	Up to 400 L/min (24 m³/h)
Max head / pressure	30 m at shut-off, 2.7 m at 400 L/min
Duty point	200 L/min at 22 m
Voltage / phase	380 V, three-phase, 50 Hz
Power	2.2 kW
Inlet / outlet	2" x 2"
Self-priming	On request
Duty cycle	On request
Fluid compatibility	Clean water, no abrasive particles, up to 40 °C
Construction	Cast iron body, brass impeller, 304 stainless steel shaft, ceramic-graphite seal
Motor protection	IP44, Class B insulation, thermal overload
Suction lift	Max 7 m
Net weight	21 kg
Shipping weight	23 kg
Dimensions	460 x 230 x 290 mm

Description

Overview

The CP80 is a high-flow pump with a 2.2 kW motor, 2″ ports, 400 L/min (24 m³/h) maximum flow and a 30 m shut-off head. It is designed for moving a lot of clean water at modest pressure.

Read the curve as 27.6 m at 100 L/min, 22 m at 200 L/min, 16.3 m at 300 L/min and 10.8 m at 350 L/min. It runs on 380 V three-phase. Suction lift is up to 7 m, liquids must be clean, non-abrasive and below 40 °C, and the build is cast iron with a brass impeller, a 304 stainless steel shaft, a ceramic-graphite seal and an IP44 motor with thermal overload protection. If you only need to boost pressure, the 2.2 kW twin-stage 2CPM25/160A reaches 60 m instead.

Key features

High flow: up to 400 L/min (24 m³/h)
2″ inlet and outlet for low friction
30 m at shut-off, 22 m at 200 L/min
Cast iron body, brass impeller, 304 stainless steel shaft
IP44 motor, thermal overload protector

Where it works

Put it on big irrigation headers, dam-to-reservoir transfers and tanker filling, on a Northern Cape lucerne farm, a Western Cape orchard or a Limpopo citrus block. It also suits clean-water circulation at packhouses. Shelter the pump under a vented cover and match the pipe to the flow. Performance data is from the manufacturer High Flow brochure. The rest of the water booster pumps range is a click away.

What’s in the box

CP80 high-flow pump, 2.2 kW 380 V three-phase
Pump only, no controller or fittings

Delivery and warranty

Kamano delivers with its own trucks from Polokwane to all nine provinces in 1 to 3 days, with regular runs to Upington, Kimberley, Cape Town, George, Polokwane and Pretoria. Delivery is charged by total order weight: up to 30 kg R550, 30 to 60 kg R950, 60 to 100 kg R1,450, and over 100 kg on quotation. At a shipping weight of 23 kg this item falls in the up to 30 kg (R550) band, and orders of R20,000 or more (VAT incl.) ship free.

Ask us for the warranty terms on this model.

Questions about this product

Which supply does the CP80 use?

The CP80 runs on 380 V, 50 Hz three-phase power. Use a starter rated for a 2.2 kW motor and check the nameplate when it arrives.

Will it suit a sprinkler block?

Yes, if the block needs volume at under about 20 m of total head. At 200 L/min you get 22 m, and at 300 L/min 16.3 m. Add elevation and pipe losses before you choose.

Do you deliver to Upington?

Yes, with our own trucks from Polokwane in 1 to 3 days. At about 23 kg the pump falls in the up to 30 kg band at R550, and orders from R20,000 ship free.
