QB-60 Peripheral Booster Pump, 0.37 kW, 38 m Head, 1″ Ports

Description

Overview

The QB-60 is a 0.37 kW peripheral vane pump that gives high pressure from a small motor: up to 38 m of head at shut-off and a maximum flow of 25 L/min (1,500 L/h). It is made for clean water and suits domestic use, especially where pressure matters more than volume.

The cast iron body carries brass inserts at the front and back of the volute to limit mineral build-up. The impeller is brass with radial peripheral vanes, the shaft is stainless steel 304 and the seal is ceramic-graphite. The motor is a single-phase 220 V, 50 Hz unit with capacitor and thermal overload protector.

Key features

• 38 m maximum head, 22 m at 10 L/min and 11 m at 20 L/min
• Brass impeller with radial peripheral vanes
• Cast iron body with brass inserts in the volute
• Stainless steel 304 shaft and ceramic-graphite mechanical seal
• Class B insulation, IP44 motor with thermal overload protector
• 1 inch inlet and outlet

Where it works

Use it to lift pressure from a header tank to one or two taps in a small home, a cottage or a farm worker house in Limpopo or Mpumalanga. It handles clean, non-aggressive water up to 40 °C with no abrasive particles, so it is not a dirty-water or borehole-sand pump. Install it under a vented cover, protected from rain and spray. This is the pump only, with no pressure switch. If you want it ready to run, look at the combo version.

Browse more water booster pumps, or compare with the QB-60 booster pump combo and the QB-70 booster pump.

What’s in the box

• 1 x QB-60 peripheral booster pump, 0.37 kW

Delivery and warranty

Kamano delivers with its own trucks from Polokwane to all nine provinces in 1 to 3 days, with regular runs to Gqeberha, East London, Cape Town, Durban, Polokwane and Johannesburg. Shipping weight is 6.5 kg, which falls in our up to 30 kg delivery band (R550). Orders of R20,000 or more (VAT incl.) are delivered free. Ask us for the warranty terms on this model.
