MA Analogue Borehole Control Box, 4 Inch Motor, 0.55 kW, 220 V

Description

Overview

This MA analogue control box starts and protects a 0.55 kW, 220 V single-phase 4 inch borehole motor. Inside are the run capacitor, an on/off switch and thermal overload protection. It is the basic way to run a single-phase borehole pump: cheap, simple and easy to replace. The capacitor is sized for the motor, so the box has to match the motor’s kW rating. Kamano supplies it from Polokwane to all nine provinces.

Key features

• Matched to a 0.55 kW, 4 inch, 220 V single-phase motor
• Run capacitor sized for the motor
• On/off switch for manual control
• Thermal overload protection
• Lowest-cost option for single-phase pumps
• No settings or display, so little to go wrong

Where it works

A 0.55 kW pump suits a modest borehole feeding a header tank or a small garden and stock supply. It is common on farms in Limpopo, North West and the Free State, and on rural homesteads where the supply is single-phase. The MA box will not stop the pump if the borehole runs dry, so on low-yield boreholes the 20Y intelligent controller is the safer choice, adding dry-run, voltage and overload protection and automatic restart. For three-phase pumps, use a Y1 or 30Y controller. Read the kW off the motor plate before you order. Neighbouring sizes include the 0.37 kW box and the 0.75 kW box, and the pump controllers page has more.

What’s in the box

• 1 x MA analogue control box for a 0.55 kW 4 inch motor

Delivery and warranty

Kamano delivers with its own trucks from Polokwane to all nine provinces in 1 to 3 days, including Rustenburg, Klerksdorp, Welkom, Bloemfontein, Mahikeng and Johannesburg. At about 1.6 kg shipped, it falls in the up to 30 kg band at R550, and free delivery applies from R20,000 VAT incl. Ask us for the warranty terms on this model.
