DTP-60 220V diesel transfer pump, 60 L/min with 1 inch ports

DTP-60 220V Diesel Transfer Pump, 60 L/min, 1″ Ports

Name: DTP-60 220V Diesel Transfer Pump, 60 L/min, 1" Ports
SKU: KMN-FUEL-0265
Price: 1842.75 ZAR
Availability: InStock

SKU KMN-FUEL-0265

A 220V sliding-vane pump that moves 60 litres of diesel or paraffin a minute through 1-inch ports, delivered by Kamano to farms, depots and workshops nationwide.

R1 842,75

Moves diesel and paraffin at 60 L/min from a standard 220V plug point
Cast-iron body with a bypass valve and a continuous-rated AC motor
370 W motor, 1″ ports, 3 m suction lift, IP55
Not for petrol

Delivered by our own trucks in 1 to 3 days. R550 / R950 / R1,450 by order weight. FREE on orders of R20,000 or more with code KH027. Delivery details

Specifications

Flow rate	60 L/min
Max head / pressure	5-7 m head
Voltage / phase	220V AC, single phase
Power	370 W, 2800 rpm
Inlet / outlet	1" / 1"
Self-priming	Yes, suction lift 3 m
Duty cycle	Continuous-rated motor
Fluid compatibility	Diesel and paraffin, 2-20 cSt (not petrol)
Pump type	Sliding-vane, cast-iron body, bypass valve
Protection	IP55
Net weight	7.4 kg
Shipping weight	7.8 kg
Dimensions	280 × 240 × 200 mm

Description

Overview

The DTP-60 is a 220V AC sliding-vane pump that transfers diesel and paraffin at 60 litres a minute. It is a straightforward way to empty a tanker, fill a farm bowser or feed a day tank wherever you have mains power. If you are shopping for a 220v diesel transfer pump that does one job without fuss, this is a sensible place to start.

Key features

60 L/min flow through 1″ ports
370 W motor turning at 2800 rpm, continuous rated
Cast-iron pump body with an internal bypass valve
Self-priming with a suction lift of about 3 m
IP55 protection against dust and splashing
Handles fluids between 2 and 20 cSt, which covers diesel and paraffin

Where it works

On the farm, a 220V diesel transfer pump earns its keep every season: filling tractors and bakkies from a bulk tank during planting in the Free State or harvest in Limpopo. Workshops and transport depots in Gauteng use the same pump to decant from drums and tanks into service vehicles. Mines and contractors run it from a site supply or a generator. It is not rated for petrol, so keep it on diesel and paraffin duty and look at the fuel transfer pumps range if you also need an explosion-proof option.

If you want more flow, compare it with the DYB-70 12V fuel transfer pump for vehicle-battery use, or the DYB-70 24V fuel transfer pump for trucks and heavy plant.

What’s in the box

DTP-60 220V transfer pump

Delivery and warranty

Kamano delivers with its own trucks from Polokwane to all nine provinces in 1 to 3 days. Orders of R20,000 or more ship free. At a shipping weight of 7.8 kg this pump falls in the lightest delivery band. Ask us for the warranty terms on this model.

Questions about this product

Can this pump handle petrol?

No. The DTP-60 is built for diesel and paraffin only and is not rated for petrol. Petrol vapour near a standard AC motor is a fire risk. If you need to move petrol, choose an explosion-proof pump from our fuel transfer range instead, such as the EX-60 220V.

How fast will it fill a 1000 litre tank?

At the rated 60 litres a minute, a 1000 litre tank takes roughly 17 minutes. Real flow drops with long hoses, a high lift or a partly blocked filter, so allow somewhat longer on site. Keep the suction hose short and the intake below 3 m to stay close to the rated figure.

Can I run it off a generator during load-shedding?

Yes. The motor is rated at 370 W, so a small petrol or diesel generator of 1 kVA or more will start and run it. Use a proper earthed lead and keep the generator well away from the fuel you are pumping. Pumps with AC motors may draw a higher current at start-up.

What does delivery cost for this pump?

The pump ships at 7.8 kg, so delivery costs R550 for orders up to 30 kg. Orders of R20,000 or more (VAT incl.) are delivered free. Kamano delivers from Polokwane with its own trucks to all nine provinces in 1 to 3 days, including farms and mine sites outside the main centres.

Nationwide delivery from Polokwane

Delivered to all nine provinces in 1 to 3 days

We deliver the DTP-60 220V Diesel Transfer Pump, 60 L/min, 1" Ports with our own trucks to Johannesburg, Pretoria, Cape Town, Durban, Gqeberha, Bloemfontein, Polokwane, Mbombela, Secunda, Kimberley, East London, Welkom, Thohoyandou and Mokopane, and to farms, mines and sites in between. This item ships in the R550 delivery band (up to 30 kg). Orders of R20,000 or more deliver free with code KH027.
