UPVC compact solvent weld ball valve with manual handle, 20 to 50 mm

UPVC Compact Ball Valve, Solvent Weld, 20 to 50 mm

SKU KMN-FITG-0028

A UPVC compact solvent weld ball valve in five sizes from 20 to 50 mm for water, slurries and corrosive liquids, delivered across South Africa from Polokwane.

Price range: R16,00 through R60,00

UPVC body, solvent weld connections
Five sizes, 20 to 50 mm, codes CBV20MM to CBV50MM
For water, corrosive fluids, slurries and other liquids
From R 16 VAT incl.

PVC Fitting Sizes

Clear

Request Bulk Quote Ask on WhatsApp

Delivered by our own trucks in 1 to 3 days. R550 / R950 / R1,450 by order weight. FREE on orders of R20,000 or more with code KH027. Delivery details

Specifications

Type	Compact ball valve, manual handle
Material	UPVC
Connection	Solvent weld
Sizes	20, 25, 32, 40 and 50 mm (by option)
Product codes	CBV20MM, CBV25MM, CBV32MM, CBV40MMG, CBV50MM
Media	Water, corrosive fluids, slurries and other liquids; gases on request
Max pressure	On request
Temperature range	On request
Net weight	0.35 kg
Shipping weight	0.45 kg
Dimensions	110 x 85 x 90 mm

Description

Overview

The UPVC compact ball valve is a solvent weld ball valve that stops or restarts flow in a pipeline when you turn the handle. It is an inexpensive, easy alternative to brass or stainless steel ball valves and comes in five sizes from 20 mm to 50 mm.

Ball valves handle flow control and shut-off for water, corrosive fluids, slurries and other liquids. The supplier also lists gases, so check with us before using it on a gas line. Being UPVC, it does not rust. Pressure and temperature ratings are not published, so ask us for the working pressure for your size. Browse the pipe fittings range for matching fittings.

Key features

UPVC body that does not rust
Solvent weld connections
Manual handle to stop and restart flow
Five sizes from 20 mm to 50 mm
Low-cost alternative to brass and stainless steel valves
Suits water, corrosive fluids, slurries and other liquids

Options

Choose the size that matches your pipe. Prices are per valve and include VAT.

20 mm (code CBV20MM): R 16
25 mm (code CBV25MM): R 18
32 mm (code CBV32MM): R 31
40 mm (code CBV40MMG): R 53
50 mm (code CBV50MM): R 60

Where it works

Isolate sections of irrigation lines on Limpopo and Free State farms, shut off sump and slurry lines at Mpumalanga mines, and fit it on dosing and chemical lines at Gauteng plants. Pair it with the brass float valve on a tank inlet or the insert nipple on LDPE pipe runs.

What’s in the box

1 x UPVC compact solvent weld ball valve (size as selected)

Delivery and warranty

Kamano delivers with its own trucks from Polokwane to all nine provinces in 1 to 3 days, including Johannesburg, Durban, Polokwane, Mbombela, Rustenburg and Kimberley. Shipping weight is about 0.45 kg. Delivery is charged by total order weight: up to 30 kg R550, 30 to 60 kg R950, 60 to 100 kg R1,450, and over 100 kg on quotation. Orders of R20,000 or more (VAT incl.) ship free. Ask us for the warranty terms on this model.

Questions about this product

What does solvent weld mean?

Solvent weld means the valve is joined to the pipe with solvent cement, which chemically fuses the UPVC into one piece. It gives a permanent joint with no threads. Cut the pipe square, clean it, apply cement and push it home, then let it cure before you pressurise the line.

Can I use it on slurry or corrosive liquids?

The supplier lists corrosive fluids and slurries among the uses for ball valves of this type. UPVC resists many chemicals, but compatibility depends on the liquid and its temperature, so tell us what is in your line and we will confirm before you order.

Which sizes and prices are available?

Five sizes are available. Prices are R 16 for 20 mm, R 18 for 25 mm, R 31 for 32 mm, R 53 for 40 mm and R 60 for 50 mm, VAT incl. Pick your size from the options on this page, and match it to the outside diameter of your pipe.

Do you deliver to Durban?

Yes. We deliver with our own trucks from Polokwane to Durban and the rest of South Africa in 1 to 3 days. One valve weighs well under 1 kg, so it falls in the up to 30 kg band at R550, and orders of R20,000 or more ship free.
