2.2 kW CPM80 Booster Pump with Pressure Switch, 400 L/min, 30 m

Description

Overview

This 2.2 kW CPM80 booster pump combo has a pressure switch fitted, so it runs automatically: it starts when you open a tap and stops when demand ends. It delivers up to 400 L/min (24 m³/h) with a maximum head of 30 m, enough for a large house, a lodge or an irrigation block. If you prefer to add your own controls, the bare CPM80 pump costs less.

The body is cast iron with a brass impeller, a 304 stainless steel shaft and a ceramic-graphite mechanical seal. The motor is single-phase 230 V, 50 Hz with a capacitor and thermal overload protector, Class B insulation and IP44 protection.

Key features

• Automatic start and stop with the fitted pressure switch
• Maximum flow 400 L/min, maximum head 30 m
• 29.1 m head at 50 L/min, 24.9 m at 150 L/min, 16.3 m at 300 L/min
• Suction lift up to 7 m
• Clean, non-aggressive water up to 40 °C

Where it works

Typical jobs are boosting pressure from a rainwater tank to a double-storey home, feeding several bathrooms at once in a Gauteng guest house, or running sprinklers off a farm storage tank. Count how many taps and showers run at the same time, then pick a pump whose head at that flow is comfortably above your lift plus pipe friction. Each 10 m of head is about 1 bar. Not sure? Send us the tank position, number of bathrooms and storeys. For a smaller house the 1.5 kW CPM70 combo may be enough. All our water booster pumps are listed together.

What’s in the box

• 1 x CPM80 2.2 kW booster pump with pressure switch

Delivery and warranty

Kamano delivers with its own trucks from Polokwane to all nine provinces in 1 to 3 days, including Johannesburg, Pretoria, Mbombela, Tzaneen, eMalahleni and Mahikeng. Shipping weight is 25 kg, which falls in our up to 30 kg delivery band of R550. Orders of R20,000 or more are delivered free. Ask us for the warranty terms on this model.
