1200 W Solar DC Borehole Pump Kit, 72 V, 180 m Head, 3HR1200-180

Description

Overview

This solar borehole pump kit lifts water from as deep as 180 m using only solar power, and it includes the pump and the matching DC controller. The 3HR1200-180 has a 1200 W, 72 V DC brushless motor, a 304 stainless steel body and casing, and a wear-resistant rubber stator. It suits off-grid and hybrid solar water pumping, and it fits boreholes, wells, rivers, dams and tanks with an internal diameter of 80 mm (3 inch) or more.

Key features

• 304 stainless steel pump body, casing, shaft and coupling
• 100% copper windings, wear-resistant rubber stator and graphite bearings
• DC brushless motor with matching DC controller included
• Soft-start control with under-voltage, over-voltage, overload and over-pumping protection
• Dry-run protection with automatic recovery
• Compact, quiet, efficient and maintenance-free
• Maximum 180 m head, maximum 2 m3/h flow

Where it works

Use it for deep boreholes on farms in Limpopo, the Northern Cape and the Free State, for livestock water, small-scale irrigation and rural households. Choose the pump by your water level, not the borehole depth: pick a model rated at least 25 to 30 percent above your actual water level, to cover pipe friction and a falling water table. The kit needs about 1800 W of solar panels, for example five 400 W panels. The water must be non-corrosive, below 40 degrees Celsius, pH 6.5 to 8.5, with sand under 1 percent. For shallower water see the 210 W 3HR pump or the 180 W LARS pump. Browse all solar pumps.

What’s in the box

• 3HR1200-180 solar borehole pump
• Matching DC controller

Delivery and warranty

Kamano delivers with its own trucks from Polokwane to all nine provinces in 1 to 3 days, including Johannesburg, Upington, Kimberley, Bloemfontein, Mahikeng and Tzaneen. At an estimated 16 kg shipped, the kit falls in the up to 30 kg band at R550. Orders of R20,000 or more (VAT incl.) qualify for free delivery. Ask us for the warranty terms on this model.
