180 W Solar DC Borehole Pump, 24 V, 50 m Head, 3LARS1.0/50-24/180

Description

Overview

This 3LARS1.0/50-24/180 is a small solar borehole pump that lifts up to 50 m on just 180 W and 24 V DC. It works like a progressive cavity pump, with a rubber stator and a rotor, so it delivers a steady flow and pressure rather than a flow that collapses as the head rises. The pump body, casing, shaft, coupling and motor housing are stainless steel, with 100 percent copper windings and graphite bearings, and the brushless motor needs no maintenance. It fits boreholes, wells, rivers, dams and tanks of 80 mm internal diameter or more.

Key features

• 180 W, 24 V DC brushless motor
• Up to 50 m head and 1.5 m3/h maximum flow
• Stainless steel pump body, casing, shaft, coupling and motor
• Soft-start control panel with under-voltage, over-voltage, overload and over-pumping protection
• Automatic recovery from running dry
• Maximum submersion depth 20 m
• 3/4 inch outlet; 3 core 2.5 mm2 cable between controller and motor

Where it works

Use it for stock watering on farms in Limpopo, the Karoo and the Northern Cape, for rural households and small gardens, and for topping up tanks. It runs from one 250 W panel (24 V) or one 330 W panel (36 V). The family of LARS pumps lifts up to 110 m, but this model’s limit is 50 m. Keep the cable between the panels and the controller under 3 m when using 2.5 mm2 cable. For deeper water see the 210 W 3HR pump or the 1200 W 3HR pump. Browse all solar pumps.

What’s in the box

• 3LARS1.0/50-24/180 solar borehole pump
• Soft-start electrical control panel

Delivery and warranty

Kamano delivers with its own trucks from Polokwane to all nine provinces in 1 to 3 days, including Johannesburg, Upington, Kimberley, Bloemfontein, Mahikeng and Tzaneen. At an estimated 8 kg shipped, the pump falls in the up to 30 kg band at R550. Orders of R20,000 or more (VAT incl.) qualify for free delivery. Ask us for the warranty terms on this model.
