4SD2/9 Solar Borehole Pump Kit, 0.75 kW 72 V DC, 88 m Head

Name: 4SD2/9 Solar Borehole Pump Kit, 0.75 kW 72 V DC, 88 m Head
SKU: KMN-SOLR-0064
Price: 7128.00 ZAR
Availability: InStock

SKU KMN-SOLR-0064

A 0.75 kW 72 V DC solar borehole pump kit with DC controller for farms and community supply, delivered across South Africa.

R7 128,00

Full DC solar kit, no mains or generator needed
Lifts up to 88 m at up to 4.75 m³/h
Stainless steel 4-inch pump, 0.75 kW brushless motor
Matching low-voltage DC controller included

Delivered by our own trucks in 1 to 3 days. R550 / R950 / R1,450 by order weight. FREE on orders of R20,000 or more with code KH027. Delivery details

Specifications

Flow rate	Up to 4.75 m³/h
Max head / pressure	88 m
Voltage / phase	72 V DC (brushless DC motor)
Power	0.75 kW
Inlet / outlet	On request
Self-priming	N/A (submersible)
Duty cycle	Daylight solar duty, soft start and dry-run recovery
Fluid compatibility	Non-corrosive water, sand up to 1% by volume, up to 40 °C
Pump type	4-inch stainless steel submersible wet end
Controller	Matching low-voltage DC solar controller included
Minimum borehole ID	100 mm (4 inches)
Recommended solar array	1650 W (three 550 W panels) at 72 V DC
Water level guide	Up to about 66 m
Net weight	14 kg
Shipping weight	19 kg
Dimensions	1100 x 300 x 250 mm

Description

Overview

The 4SD2/9 kit on 72 V DC pairs a 4-inch stainless steel submersible pump and a 0.75 kW brushless DC motor with a matching low-voltage DC controller, reaching 88 m head at up to 4.75 m³/h.

It is a full DC solar kit, so no mains electricity or generator is needed. The controller runs the motor straight from the panels with soft start and protection against under-voltage, over-voltage, overloading and dry running, with automatic recovery. It fits 4-inch (100 mm) and larger boreholes, wells and reservoirs, and gives more flow than a 3-inch kit. Water should be non-corrosive with sand below 1 percent by volume, up to 40 °C.

Key features

Stainless steel 4-inch submersible pump wet end
Brushless DC (BLDC) motor, 0.75 kW, with 100% copper windings
Matching low-voltage DC solar controller included
Full DC system on 72 V DC, no mains or generator needed
Soft start with dry-run automatic recovery
Rated for water levels up to about 66 m
Designed for a 1650 W (three 550 W panels) solar array

Where it works

A full DC kit suits citrus and vegetable farms in Mpumalanga, livestock watering, irrigation and community water projects that need more flow than a 3-inch kit can give. Measure the depth to the water, not the total borehole depth, and allow for friction losses and a dropping water table. The 4SD range reaches 240 m head, so ask us if your borehole is deeper or you need more water per hour.

Browse the full solar pump range, or compare the 4SD2/9 solar kit, 48 V DC, 83 m head and the 4SD2/9 solar kit, 110 V DC, 105 m head.

What’s in the box

4-inch stainless steel submersible pump end
Brushless DC submersible motor (0.75 kW)
Matching low-voltage DC solar controller
Not included: solar panels, cable and pipework

Delivery and warranty

Kamano delivers with its own trucks from Polokwane to all nine provinces in 1 to 3 days, including Polokwane, Mbombela, eMalahleni, Pretoria, Johannesburg and Richards Bay. This item ships at about 19 kg, which puts delivery in the up to 30 kg (R550) band, and orders of R20,000 or more (VAT incl.) ship free. Ask us for the warranty terms on this model.

Questions about this product

How many solar panels does the 4SD2/9 kit need?

This kit is designed for a 1650 W solar array, three standard 550 W panels wired together, at 72 V DC. That is larger than the motor rating on purpose, to cover cloudy days, cable and controller losses and imperfect sun angles. The count is based on 550 W panels, so other wattages change the number. Tell us your site and we will confirm the setup.

Is this the right 4SD kit for my borehole?

The 4SD2/9 kit is rated for water levels up to about 66 m at roughly 4.75 m³/h. Measure the depth to the water, not the total borehole depth. If your water is deeper or you need a different flow, the 4SD range runs up to 240 m head, so ask us to match the right configuration before you order.

Do I need mains power or a generator for this kit?

No. It is a full DC solar kit, so no mains electricity or generator is required. The matching low-voltage DC controller runs the brushless motor straight from the panels, with soft start and protection against under-voltage, over-voltage, overloading and dry running. If you want mains or generator back-up as well, look at our hybrid 4SD kits instead.

Do you deliver to Polokwane?

Yes. Kamano delivers with its own trucks from Polokwane to all nine provinces, usually in 1 to 3 days, including Polokwane. This item ships at about 19 kg, so delivery falls in the up to 30 kg (R550) band. Orders of R20,000 or more (VAT incl.) ship free. Tell us your site address and we confirm the delivery fee and timing before you pay.
