Two-Cavity Wall Retaining Block Machine, 470 × 180 × 300 mm

Description

Overview

This retaining block machine is a manual two-cavity mould that casts concrete wall retaining blocks measuring 470 × 180 × 300 mm. The blocks are used on embankments, attenuation ponds and cut slopes to hold back soil and control erosion.

Two blocks per drop doubles your pace against our single-cavity model, and because it is manual you can cast right at the slope without a power point. That saves hauling heavy blocks across a site.

Key features

• Two cavities per drop
• Block size 470 × 180 × 300 mm
• Manual, no motor
• Steel construction
• Cast on site to save transport

Where it works

Use this retaining block machine for road cuttings and embankments on municipal and provincial jobs, stormwater attenuation ponds in new developments in Gauteng, and erosion control on farm roads and dam walls in KZN and Mpumalanga. Landscapers also use it for terraced gardens. For curved walls, the round block version casts round blocks. See all brick making machines.

Retaining blocks are heavy, so cast them as close to the wall as you can and give them a full week of damp curing before moving them. Use a well-graded mix with stone for strength, keep the mould clean between casts, and set the first course on a compacted, level footing.

What’s in the box

• Two-cavity wall retaining block machine (manual)

Delivery and warranty

Kamano delivers with its own trucks from Polokwane to all nine provinces, usually within 1 to 3 days. Orders of R20,000 or more (VAT incl.) travel free. The machine ships at 54 kg, which falls in the 30 to 60 kg band at R950 to anywhere in South Africa. Not sure which machine suits your yard? Send us your target daily output and the products you want to make, and we will help you choose. Ask us for the warranty terms on this model.
