Pulser pulse transmitter with cable for M-40, M-50 and M-80 bulk flowmeter registers

Pulser for M-40, M-50 and M-80 Bulk Flowmeter Registers

Name: Pulser for M-40, M-50 and M-80 Bulk Flowmeter Registers
SKU: KMN-FUEL-0083
Price: 2504.25 ZAR
Availability: InStock

SKU KMN-FUEL-0083

A pulse transmitter that adds an electronic output to M-40, M-50 and M-80 bulk flowmeter registers, for fuel management systems, delivered nationwide from Polokwane.

R2 504,25

Turns the mechanical meter reading into an electronic pulse signal
Feeds a fuel management system, PLC or remote display
Fits M-40, M-50 and M-80 registers (code S/A-MP)
Keeps the mechanical register working as a backup

Delivered by our own trucks in 1 to 3 days. R550 / R950 / R1,450 by order weight. FREE on orders of R20,000 or more with code KH027. Delivery details

Specifications

Part type	Pulse transmitter (pulser)
Code	S/A-MP
Fits	M-40, M-50 and M-80 registers
Output signal	On request
Pulses per litre	On request
Supply voltage	On request
Flow range	N/A (set by the meter)
Max pressure	N/A (accessory)
Material	Aluminium alloy housing
Net weight	0.7 kg
Shipping weight	1 kg
Dimensions	120 × 75 × 110 mm

Description

Overview

This flowmeter pulser is a pulse transmitter that fits to the register of M-40, M-50 and M-80 bulk meters and sends a train of electronic pulses as fuel passes. Each pulse stands for a set volume, so a fuel management system, PLC or remote counter can total the delivery without anyone reading the dial.

The mechanical register keeps working, which gives you a backup reading if the electronics or cabling fail. That is the simplest way to bring an existing mechanical meter into an automated system without replacing it.

Output type, pulses per litre and supply voltage are confirmed per order, so tell us what the pulser will connect to before you buy and we will match it.

Key features

Pulse transmitter for M-series mechanical registers
Fits M-40, M-50 and M-80 meters
Electronic output for fuel systems and remote displays
Mechanical register stays as a backup reading
Compact unit at 0.7 kg

Where it works

Use a flowmeter pulser where fuel use must flow straight into software: mine fuel bays that allocate diesel per machine, transport depots in KZN running fuel management systems, municipalities logging fleet fuel, and depots with a control room display. It also suits farms upgrading an existing M-series meter instead of buying a digital one. Fit it to a M-80 3″ bulk flowmeter or add it after replacing a worn head with a mechanical register for bulk flowmeters. Browse more flowmeter accessories.

What’s in the box

M-series pulser

Delivery and warranty

Kamano delivers with its own trucks from Polokwane to all nine provinces in 1 to 3 days. The pulser ships at about 1 kg, which puts it in the up to 30 kg band (R550). Delivery is free on orders of R20,000 or more, so it is worth adding the rest of your fuel kit to the same order. Ask us for the warranty terms on this model.

Questions about this product

Will the pulser work with my fuel management system?

Most fuel management systems and PLCs accept a pulse input, but signal type, voltage and pulses per litre must match. Send us the make and model of your controller and its input specification, and we will confirm the pulser setup before you order. That saves a wasted trip to site.

Does the pulser fit the M-100 meter?

This pulser is listed for the M-40, M-50 and M-80 registers. The M-100 uses a different decalitre register, so ask us about a pulser for that model. Send a photo of the register face and the meter nameplate and we will check what fits.

Do you deliver to Pietermaritzburg, and what does it cost?

Yes. Our own trucks run from Polokwane to all nine provinces, normally in 1 to 3 days, and Pietermaritzburg is on the route. The pulser weighs about 1 kg packed, so on its own it falls in the up to 30 kg band (R550). Add enough to reach R20,000 including VAT and the whole order ships free.
