DYB-100 12V diesel transfer pump, 90 to 100 L/min rotary-vane unit

DYB-100 12V Diesel Transfer Pump, 90-100 L/min, 1″ Ports

Name: DYB-100 12V Diesel Transfer Pump, 90-100 L/min, 1" Ports
SKU: KMN-FUEL-0267
Price: 3449.25 ZAR
Availability: InStock

SKU KMN-FUEL-0267

A 12V rotary-vane diesel pump moving 90 to 100 litres a minute, built for refuelling trucks and plant from a battery, delivered by Kamano nationwide.

R3 449,25

90-100 L/min from a 12V battery supply, for fast truck and plant refuelling
600 W motor, cast-iron body, 15 m maximum head
1″ ports with a 3 m suction lift
Steel rotor, inlet filter and thermal overload protection

Delivered by our own trucks in 1 to 3 days. R550 / R950 / R1,450 by order weight. FREE on orders of R20,000 or more with code KH027. Delivery details

Specifications

Flow rate	90-100 L/min
Max head / pressure	15 m head
Voltage / phase	12V DC
Power	600 W
Inlet / outlet	1" / 1"
Self-priming	Yes, suction lift 3 m
Duty cycle	On request
Fluid compatibility	Diesel and paraffin (not petrol)
Body material	Cast iron
Net weight	13.8 kg
Shipping weight	15.0 kg
Dimensions	330 × 190 × 190 mm

Description

Overview

The DYB-100 12V is a rotary-vane pump that transfers diesel at 90 to 100 litres a minute straight from a vehicle or battery bank. It suits anyone who needs bulk refuelling speed without mains power. If you are comparing a 12v diesel transfer pump 100 l/min, this is the high-flow end of the 12V range.

Key features

90-100 L/min flow through 1″ ports
600 W motor with a cast-iron pump body
Maximum head of 15 m and suction lift of 3 m
Steel rotor and a 100-micron inlet filter to protect the vanes
IP55 motor with thermal overload protection
Self-priming, so it clears the suction line on its own

Where it works

This is the pump for fuel bakkies and service trucks on mine sites in Mpumalanga and Limpopo, and for road contractors who refuel excavators and graders at the face. Farmers use it to fill tankers and pivot-service vehicles from a bulk tank during harvest. It also suits depots that lose mains power during load-shedding. Diesel and paraffin only: keep petrol away from it.

The same pump is also sold as the DYB-100 24V version for heavy trucks and the DYB-100 220V version for mains installations. Browse the full range of fuel transfer pumps to compare flow rates.

What’s in the box

DYB-100 12V transfer pump

Delivery and warranty

Kamano delivers with its own trucks from Polokwane to all nine provinces in 1 to 3 days. Orders of R20,000 or more ship free. Shipping weight is 15 kg. Ask us for the warranty terms on this model.

Questions about this product

Can I run this pump off a bakkie battery?

Yes, it runs on 12V DC, but at 600 W it is a heavy load. Connect it with thick cable and a proper fuse, and keep the engine running while you pump so the battery does not go flat. A short run of cable with solid clamps gives the best flow.

How long does it take to fill a truck tank?

At 90 to 100 litres a minute, a 400 litre truck tank takes about four to five minutes in ideal conditions. Long hoses, a high lift or a clogged filter will slow that, so keep the suction hose short and clean the inlet filter regularly.

Is it suitable for petrol?

No. It is built for diesel and paraffin and is not rated for petrol. The motor is not explosion-proof, so petrol vapour would be a fire risk. For petrol, ask us about the EX series of explosion-proof pumps in our fuel transfer range.

What will delivery cost to my farm?

The pump ships at 15 kg, so delivery is R550 for orders up to 30 kg. Orders of R20,000 or more (VAT incl.) are delivered free. We deliver from Polokwane with our own trucks to all nine provinces in 1 to 3 days, including remote farms.
