DYB-100 24V diesel transfer pump, 90 to 100 L/min rotary-vane unit

DYB-100 24V Diesel Transfer Pump, 90-100 L/min, 1″ Ports

Name: DYB-100 24V Diesel Transfer Pump, 90-100 L/min, 1" Ports
SKU: KMN-FUEL-0269
Price: 3449.25 ZAR
Availability: InStock

SKU KMN-FUEL-0269

A 24V rotary-vane diesel pump delivering 90 to 100 litres a minute from truck and plant electrical systems, supplied by Kamano nationwide.

R3 449,25

Runs straight off a 24V truck or plant battery system
90-100 L/min through 1″ ports, 15 m maximum head
600 W motor and cast-iron body
Inlet filter and thermal overload protection

Delivered by our own trucks in 1 to 3 days. R550 / R950 / R1,450 by order weight. FREE on orders of R20,000 or more with code KH027. Delivery details

Specifications

Flow rate	90-100 L/min
Max head / pressure	15 m head
Voltage / phase	24V DC
Power	600 W
Inlet / outlet	1" / 1"
Self-priming	Yes, suction lift 3 m
Duty cycle	On request
Fluid compatibility	Diesel and paraffin (not petrol)
Net weight	13.8 kg
Shipping weight	15.0 kg
Dimensions	330 × 190 × 190 mm

Description

Overview

The DYB-100 24V is a rotary-vane pump for moving diesel at 90 to 100 litres a minute from a 24V electrical system. Heavy trucks, loaders and generators sets with 24V batteries can power it directly, which makes it the natural fit for fuel trucks and mining plant. A 24v diesel transfer pump at this flow turns a long refuel into a short one.

Key features

90-100 L/min flow through 1″ ports
600 W motor for 24V DC systems
Cast-iron body and steel rotor
15 m maximum head and 3 m suction lift
100-micron inlet filter to protect the vanes
IP55 motor with thermal overload protection

Where it works

Coal mines in Mpumalanga and the platinum belt around Rustenburg run 24V diesel pumps on service trucks, filling haul trucks and dozers at the pit. Road and civil contractors in Limpopo and KZN use the same arrangement on lube and fuel vehicles. Plant hire yards fit them to site bowsers so a machine can be refuelled wherever it stops. It is for diesel and paraffin only.

If your vehicle runs on 12V instead, the DYB-100 12V pump gives the same flow class, while the DTP-110 220V pump suits fixed mains installations. Compare options in our fuel transfer pumps range.

What’s in the box

DYB-100 24V transfer pump

Delivery and warranty

Kamano delivers with its own trucks from Polokwane to all nine provinces in 1 to 3 days. Orders of R20,000 or more ship free. Shipping weight is 15 kg. Ask us for the warranty terms on this model.

Questions about this product

Can I power this from a 12V bakkie battery?

No. This version is built for 24V systems and will not perform on 12V. For a bakkie, choose the 12V DYB-100 instead. Trucks and heavy plant with two 12V batteries in series are normally 24V and suit this pump, but check the vehicle wiring first.

How fast does it refuel a haul truck?

The rated flow is 90 to 100 litres a minute, so 500 litres goes in within about five or six minutes under good conditions. A short suction line, a clean inlet filter and a wide delivery hose help you stay close to rated flow.

Does it pump petrol?

No, it is for diesel and paraffin only and is not rated for petrol. Petrol needs an explosion-proof pump. Look at the EX series in our fuel transfer category if you need to move petrol safely.

How much is delivery to a mine outside Rustenburg?

The pump ships at 15 kg, so delivery is R550 for orders up to 30 kg. Orders of R20,000 or more (VAT incl.) are free. We deliver from Polokwane with our own trucks to all nine provinces in 1 to 3 days, including mine sites around Rustenburg.
