20 mm Compact PVC Ball Valve, BSP Threaded, 16 bar, CBV20MMT

Description

Overview

The 20 mm compact PVC ball valve is a threaded shut-off valve for the most common pipe size on household pressure pumps, tank outlets and garden and farm supply lines. It has BSP threads, a quarter-turn handle and a maximum pressure of 16 bar, and the compact body fits into tight spots next to pumps, filters and manifolds.

Because it is PVC, it does not rust, it is light, and it is cheap enough to fit at every branch so you can isolate a section without draining the whole system.

Key features

• 20 mm BSP threaded connections
• Compact PVC body
• Quarter-turn open and close
• Maximum pressure 16 bar
• Corrosion free
• Model code CBV20MMT, barcode 6009507865444

Where it works

Use it on pump inlets and outlets, ahead of a filter, at tank outlets and at the start of each irrigation line on Limpopo, Mpumalanga and Western Cape farms. In pool and pond plumbing it isolates a pump or skimmer line. Seal the thread with PTFE thread seal tape, and turn the nut or fitting by hand and then a little further, so the plastic thread is not stressed. Smaller and larger sizes are available, including the 15 mm and 25 mm valves. See all pipe fittings.

What’s in the box

• 1 x 20 mm compact PVC ball valve, BSP threaded

Delivery and warranty

Kamano delivers with its own trucks from Polokwane to all nine provinces in 1 to 3 days, including Johannesburg, Rustenburg, Klerksdorp, Bloemfontein, Durban and Gqeberha. A valve ships at about 0.08 kg, so it sits in the lowest delivery band (R550 for orders up to 30 kg). Delivery is free on orders of R20,000 or more (VAT incl.). Ask us for the warranty terms on this model.
