4 Inch Borehole Motor 2.2 kW 525 V Three Phase, Oil Filled

Description

Overview

This 2.2kW 4 inch borehole motor is an oil-filled submersible motor for 525 V three-phase supply, built to drive a matching Vega 4SD or 4ST pump end of the same power rating and rated for 20 bar.

A 2.2 kW motor is for deeper boreholes or higher-head duty where the smaller motors run out of push. 525 V motors are normally run with a variable speed drive, so see our VSD range.

It comes with a 2 m lead-out cable, so measure the run from the borehole head to your isolator before you order. The motor is sold without a pump end, so it suits a replacement job or a rebuild of an existing borehole set. Model code 10060108. Browse the full borehole pumps and motors range for matching pump ends.

Key features

• Oil-filled 4 inch submersible motor, 2.2kW
• Supply: 525 V three phase
• Rated for 20 bar
• 2 m lead-out cable
• Fits boreholes of 100 mm and larger
• Matches Vega 4SD and 4ST pump ends of the same power rating
• Normally run from a variable speed drive

Where it works

A 2.2kW 4 inch borehole motor is the part farmers in Mpumalanga and installers around the country fit when a set burns out or a pump end is being rebuilt, and a spare in the bakkie saves a second trip. A 525 V winding is a specialist option normally driven by a VSD, so confirm your drive output voltage before you order. Compare it with the 1.1 kW 220 V three-phase motor for VSDs or the 1.1 kW 380 V three-phase motor.

What’s in the box

• 4 inch oil-filled submersible borehole motor, 2.2kW
• 2 m lead-out cable
• Motor only: pump end and control gear sold separately

Delivery and warranty

Kamano delivers with its own trucks from Polokwane to all nine provinces in 1 to 3 days, including eMalahleni, Richards Bay, Johannesburg, Durban, Polokwane and Kimberley. This 2.2kW 4 inch borehole motor ships at about 18 kg, so it falls in the up to 30 kg band at R550. Fees are by total order weight: up to 30 kg R550, 30 to 60 kg R950, 60 to 100 kg R1,450, over 100 kg on quotation, and orders of R20,000 or more (VAT incl.) ship free. Ask us for the warranty terms on this model.
