2.2 kW Raw Sewage Pump, 380 V Three-Phase, 50 mm Outlet, 40 mm Solids

Name: 2.2 kW Raw Sewage Pump, 380 V Three-Phase, 50 mm Outlet, 40 mm Solids
SKU: KMN-SUBM-0046
Price: 10128.00 ZAR
Availability: InStock

SKU KMN-SUBM-0046

A 2.2 kW three-phase raw sewage pump with cutter inlet, 17 m head and 40 mm solids passage, delivered by Kamano across South Africa.

R10 128,00

Up to 35 m3/h and 17 m maximum head
Cutter inlet, 40 mm solids passage
380 V to 415 V three-phase, 5 A
IP68 motor with double mechanical seal

Delivered by our own trucks in 1 to 3 days. R550 / R950 / R1,450 by order weight. FREE on orders of R20,000 or more with code KH027. Delivery details

Specifications

Flow rate	Up to 35 m3/h
Max head / pressure	17 m
Voltage / phase	380 V to 415 V, three-phase
Power	2.2 kW (3 HP), 2-pole
Rated current	5 A
Inlet / outlet	Cutter inlet / 50 mm outlet
Self-priming	N/A (submersible)
Duty cycle	On request
Fluid compatibility	Raw sewage and sludge up to 40 °C, density 1.3 g/cm3, pH 6 to 10
Impeller	Cast iron, open single channel, 40 mm passage
Seal	Double mechanical, silicon carbide/silicon carbide and carbon graphite/ceramic
Protection class	IP68, Class B
Max immersion depth	10 m
Power cable	8 m
Net weight	31 kg
Shipping weight	34 kg
Dimensions	320 x 300 x 520 mm

Description

Overview

This 2.2 kW (3 HP) three-phase raw sewage pump has a 50 mm outlet and a cutter inlet. It moves up to 35 m3/h and lifts to 17 m, and the 40 mm impeller passage takes bulkier effluent than the smaller models. The star-shaped inlet holds stringy solids against the plate while the open vane impeller cuts them to size, and an adjustable bottom plate maintains the clearance as the impeller wears. It draws 5 A on 380 V to 415 V supply.

Key features

Integrated cutter mechanism at the inlet
40 mm impeller passage
Cast iron body and cast iron open single channel impeller
Adjustable bottom plate for impeller clearance
Double mechanical seal, silicon carbide/silicon carbide and carbon graphite/ceramic
IP68, 10 m maximum immersion depth, 8 m cable

Where it works

Fit it in septic and conservancy systems at game lodges and estates in Limpopo and the Eastern Cape, in dairy and piggery effluent pits, in municipal pump stations with long rising mains, and in mine compound sumps. Its 17 m head helps where the discharge climbs. Compare the 1.5 kW 380 V raw sewage pump for less lift, or move up to the 11 kW raw sewage pump when flow outgrows a 50 mm line. Browse our submersible pumps.

What’s in the box

2.2 kW three-phase raw sewage pump with cutter inlet
8 m power cable

Delivery and warranty

Kamano delivers with its own trucks from Polokwane to all nine provinces in 1 to 3 days, with regular runs to East London, Gqeberha, George, Durban, Johannesburg, Polokwane and Bloemfontein. Fees are set by total order weight: up to 30 kg R550, 30 to 60 kg R950, 60 to 100 kg R1,450, and over 100 kg on quotation. At 34 kg shipping weight this pump sits in the 30 to 60 kg band at R950. Orders of R20,000 or more (VAT incl.) ship free. Ask us for the warranty terms on this model.

Questions about this product

Which sewage pump do I need for a long rising main?

This 2.2 kW model lifts to 17 m. Add pipe friction and static lift together to get your total head. If the total is close to 17 m, ask us to check the duty point.

Does the cutter stop it blocking?

It reduces blockages from rags and fibre, because the star inlet holds stringy solids while the impeller cuts them. It cannot cut hard objects, so keep sanitary products in bulk, stones and plastic sheeting out of the pit.

Do you deliver this pump to East London?

Yes. Kamano delivers with its own trucks from Polokwane to East London and the rest of South Africa in 1 to 3 days. This pump ships at 34 kg, which is the 30 to 60 kg band at R950. Orders of R20,000 or more (VAT incl.) ship free.
