Vega DL5-110 Multistage Pump Wet End, 2.2 kW, 8 m³/h, 70 m

Description

Overview

The DL5-110 is a vertical multistage centrifugal pump built for reliable, high-pressure water delivery in South African homes, farms and industrial sites. It moves up to 8 m³/h at a maximum head of 70 m and takes a 2.2 kW three-phase motor. This listing is for the pump wet end only. The motor is sold separately.

Step down to the DL5-100 with a 1.5 kW motor for 64 m, or up to the DL5-120 for 75 m. A worn DL5 can often be revived with a replacement hydraulic stack. See the multistage pump category for the rest.

Key features

• Maximum flow of 8 m³/h and maximum head of 70 m
• Rated motor power of 2.2 kW on a 380 V, 50 Hz three-phase supply, with 220 V and 525 V motor options also available
• Vertical multistage construction with a stainless steel impeller stack
• Compact upright body that fits a small pump room
• Wet end only, so the motor and starter are your choice

Where it works

The DL5-110 suits borehole water supply, rainwater harvesting, domestic pressure boosting, garden irrigation and small rural water schemes. Typical jobs are a KZN lifestyle estate irrigation line, a Mpumalanga farmstead with a header tank, or a Western Cape homestead on rainwater. Measure the head you need, including pipe friction and the height of the highest tap, before you choose.

What’s in the box

• DL5-110 vertical multistage pump wet end
• Motor not included, sold separately

Delivery and warranty

Kamano delivers with its own trucks from Polokwane to all nine provinces in 1 to 3 days, with runs to Durban, Pietermaritzburg, Mbombela, Cape Town, George and Rustenburg. Shipping weight is 19 kg, in the up-to-30 kg band (R550), and orders of R20,000 or more (VAT incl.) ship free. Ask us for the warranty terms on this model.
