Air eliminator assembly for M40, M50, M80 and M100 bulk fuel flowmeters

Air Eliminator for M40 to M100 Bulk Flowmeters, 10.5 bar

Name: Air Eliminator for M40 to M100 Bulk Flowmeters, 10.5 bar
SKU: KMN-FUEL-0051
Price: 4961.25 ZAR
Availability: InStock

SKU KMN-FUEL-0051

An air eliminator assembly for M40, M50, M80 and M100 bulk flowmeters that vents trapped air before it is counted, delivered from Polokwane nationwide.

R4 961,25

Vents air before it reaches the meter, so you only pay for fuel
Cuts over-reading at the start and end of tanker drops
Fits M40, M50, M80 and M100 bulk meters
10.5 bar working pressure

Delivered by our own trucks in 1 to 3 days. R550 / R950 / R1,450 by order weight. FREE on orders of R20,000 or more with code KH027. Delivery details

Specifications

Part type	Air eliminator assembly, part code S/A-A1
Flow range	N/A (accessory)
Accuracy	N/A (accessory)
Connection size	Universal fit M40, M50, M80 and M100 meters
Max pressure	10.5 bar
Material	On request
Display type	N/A (accessory)
Net weight	1.5 kg
Shipping weight	1.65 kg
Dimensions	190 × 200 × 270 mm

Description

Overview

This air eliminator for bulk meter installations is the venting assembly that sits ahead of an M40, M50, M80 or M100 flowmeter. It collects air and vapour that enter the line, mostly when a tank compartment runs low, and releases it through a vent so the meter only counts liquid. It is rated to 10.5 bar working pressure.

A bulk meter cannot tell air from diesel. Without a working air eliminator, every slug of air that passes is counted as fuel, and on a busy tanker that adds up to real money every month. When a meter starts reading high, this unit is one of the first parts we check, along with the outlet check valve. Part code S/A-A1.

Key features

Universal fit across M40, M50, M80 and M100 bulk meters
Releases air and vapour before measurement
Rated to 10.5 bar working pressure
Light assembly of about 1.5 kg for easy field replacement
Works with the float-stop internals in the strainer housing

Where it works

Fuel distributors, tanker fleets running between Durban and Gauteng, and mines with bulk diesel stations use this air eliminator for bulk meter lines to keep deliveries honest. Pair it with the 2″ check valve on M40 and M50 meters, or with a mechanical register for bulk flowmeters when you rebuild a meter. All bulk meter spares sit in our fuel flowmeters range.

What’s in the box

1 × air eliminator assembly

Delivery and warranty

Kamano delivers with its own trucks from Polokwane to all nine provinces, normally in 1 to 3 days. This item ships at 1.65 kg, which puts it in the up-to-30 kg band at R550. Orders of R20,000 or more (VAT incl.) travel free, so it pays to combine it with a bigger order. Ask us for the warranty terms on this model.

Questions about this product

Why does my tanker meter read more than I delivered?

Air is the usual reason. As a compartment empties, the pump draws air and vapour along with the fuel, and the meter counts it. A working air eliminator vents that air before the meter. If yours is blocked, stuck or missing, replace it and check the outlet check valve at the same time.

Does it fit all M-series meters?

It is listed as a universal fit for M40, M50, M80 and M100 bulk flowmeters. Different makers do vary slightly, so send us your meter model or a photo of the strainer housing before you order. We will confirm the fit so you are not left with a tanker standing in the yard.

How much does delivery cost to Bloemfontein?

The air eliminator ships at 1.65 kg, which is in the up-to-30 kg band at R550, Bloemfontein included. Our own trucks run from Polokwane and normally arrive within 1 to 3 days. If your spares order comes to R20,000 or more including VAT, delivery is free.
