0.75 kW 525 V three-phase variable speed drive for pumps

Variable speed drive 0.75 kW 525 V side view

0.75 kW Variable Speed Drive, 525 V, Soft Start and Dry-Run Protection

Name: 0.75 kW Variable Speed Drive, 525 V, Soft Start and Dry-Run Protection
SKU: KMN-VSDC-0025
Price: 6400.00 ZAR
Availability: InStock

SKU KMN-VSDC-0025

A 0.75 kW 525 V frequency inverter with soft start/stop and overload and dry-run protection, delivered across South Africa.

R6 400,00

0.75 kW (1 HP) pump variable speed drive
525 V three-phase supply
Changes motor speed by altering frequency
Soft start/stop and overload/dry-run protection

Delivered by our own trucks in 1 to 3 days. R550 / R950 / R1,450 by order weight. FREE on orders of R20,000 or more with code KH027. Delivery details

Specifications

Power	0.75 kW / 1 HP
Voltage / phase	525 V, three-phase
Rated current	On request
Function	Frequency inverter, varies motor speed by altering frequency
Protection	Soft start/stop, overload and dry-run protection
Application	Pump motors
Enclosure rating	On request
Net weight	1.3 kg
Shipping weight	2 kg
Dimensions	190 x 120 x 150 mm

Description

Overview

This 0.75 kW 525 V variable speed drive is a frequency inverter from the F2/3053 range that controls pump motor speed, with soft start/stop and overload and dry-run protection for pump applications. The 525 V rating suits sites on a 525 V supply, such as mines and some industrial plants. Browse the full range under pump controllers and VSDs.

Key features

0.75 kW / 1 HP rating
525 V, three-phase supply
Alters frequency to speed up or slow down the pump motor
Lets the pump match its duty to the job at hand
Soft start and soft stop for gentler starts on the pump and pipework
Overload and dry-run protection for the pump motor

Where it works

Use it on a small pump that sits on a 525 V supply: a mine workshop, a plant sump or a process transfer pump. Soft starting is gentler on the pump and pipework, and dry-run protection helps when a suction source runs low. Contact us to confirm the correct rating for your pump motor size and supply voltage before ordering.

Related ratings: the 1.5 kW 525 V drive and the 0.75 kW 380 V drive. Not sure which one fits? Send us the motor nameplate and we will confirm.

What’s in the box

1 x variable speed drive (0.75 kW 525 V)

Delivery and warranty

Kamano delivers with its own trucks from Polokwane to all nine provinces in 1 to 3 days, including eMalahleni, Rustenburg, Welkom, Klerksdorp, Johannesburg and Polokwane. Delivery fees are set by total order weight: up to 30 kg R550, 30 to 60 kg R950, 60 to 100 kg R1,450, and over 100 kg on quotation. Orders of R20,000 or more (VAT incl.) are delivered free. This drive ships at about 2 kg, so it falls in the first delivery band. Ask us for the warranty terms on this model.

Questions about this product

What protection does this drive give the pump?

It provides motor speed control, soft start and soft stop, and overload and dry-run protection for pump applications. Those protections help the pump motor on a weak suction or a blocked line.

Where is a 525 V supply used?

525 V three-phase is common on mines and some industrial sites. Confirm your site voltage and the motor rating before you order, and contact us if you want the rating checked.

Is the rated current listed?

The rated current is not listed for this model, so send us your motor nameplate and we will confirm the fit before you order.

Do you deliver this drive to eMalahleni?

Yes. Kamano delivers from Polokwane to all nine provinces in 1 to 3 days, including eMalahleni. At about 2 kg it falls in the up-to-30 kg band at R550, and orders of R20,000 or more are delivered free.
