0.25 kW 380 V three-phase submersible pump, 9 m3/h, 40 mm outlet

0.25 kW 380 V three-phase submersible pump, 9 m3/h, 40 mm outlet, side view

0.25 kW 380 V three-phase submersible pump, 9 m3/h, 40 mm outlet, close-up detail

0.25 kW Three-Phase Submersible Pump, 380 V, 8 m Head

Name: 0.25 kW Three-Phase Submersible Pump, 380 V, 8 m Head
SKU: KMN-SUBM-0036
Price: 2146.00 ZAR
Availability: InStock

SKU KMN-SUBM-0036

A 0.25 kW, 380 V three-phase submersible pump moving 9 m3/h for sumps and screened sewage, delivered across South Africa.

R2 146,00

Three-phase 380 V to 415 V motor
Handles clean water, dirty water and screened sewage
0.25 kW (0.33 HP), 40 mm outlet
9 m3/h flow at 3 m, 8 m maximum head

Delivered by our own trucks in 1 to 3 days. R550 / R950 / R1,450 by order weight. FREE on orders of R20,000 or more with code KH027. Delivery details

Specifications

Flow rate	Up to 9 m3/h (150 L/min)
Max head / pressure	8 m
Duty point	9 m3/h at 3.0 m
Performance curve	8.0 m at 0 m3/h, 7.0 m at 3 m3/h, 5.0 m at 6 m3/h, 3.0 m at 9 m3/h
Voltage / phase	380 V to 415 V three-phase
Power	0.25 kW (0.33 HP)
Inlet / outlet	Outlet 40 mm, suction through removable screen
Self-priming	N/A (submersible)
Duty cycle	On request
Fluid compatibility	Clean water, dirty water and screened sewage up to 40 °C, liquid density 1 kg/l
Construction	Cast-iron body and open-vane impeller, double stainless steel mechanical seal, nitrile elastomer
Max immersion depth	5 m
Power cable	10 m
Float switch	Not listed for this version
Motor protection	Use a motor starter with overload protection
Net weight	7 kg
Shipping weight	8 kg
Dimensions	240 x 180 x 300 mm

Description

Overview

This 0.25 kW three-phase submersible pump moves up to 9 m3/h with 8 m of head from a 380 V supply, and is the one to pick when a 0.18 kW unit is too slow for your sump.

It delivers up to 9 m3/h (150 L/min), with 8 m of maximum head and a duty point of 9 m3/h at 3.0 m. The 380 V to 415 V three-phase motor suits sites with a three-phase supply. Wire it through a motor starter with overload protection and check the direction of rotation before you put it in service. The cast-iron body and open-vane impeller are designed for screened sewage and dewatering, and the removable suction screen keeps larger debris out.

Key features

0.25 kW (0.33 HP) motor, 380 V to 415 V three-phase
8 m maximum head and 9 m3/h (150 L/min) flow
Cast-iron pump body with a cast-iron open-vane impeller
Removable suction screen, so one pump covers screened sewage and dewatering
Double stainless steel mechanical seal (graphite/ceramic and graphite/silicon carbide) with nitrile elastomer
10 m power cable, maximum immersion depth 5 m, liquid temperature up to 40 °C

Where it works

It earns its keep in workshop pits, mine sumps and plant drains where three-phase power is already wired, such as Free State gold-field services and Gauteng factories, and on farms with a three-phase pump house. Use the 0.25 kW 220 V version on single-phase power, or the 0.55 kW 380 V pump when you need 20 m3/h. Browse the full submersible pump range.

What’s in the box

0.25 kW submersible pump with 10 m power cable
Removable suction screen
Hose and discharge fittings are not included

Delivery and warranty

Kamano delivers with its own trucks from Polokwane to all nine provinces in 1 to 3 days, with regular runs to Johannesburg, Welkom, Klerksdorp, Kimberley, Polokwane and Rustenburg. Delivery is charged by total order weight: up to 30 kg R550, 30 to 60 kg R950, 60 to 100 kg R1,450 and over 100 kg on quotation, and orders of R20,000 or more (VAT incl.) go free. At about 8 kg shipping weight this item falls in the up to 30 kg (R550) band. Ask us for the warranty terms on this model.

Questions about this product

Is a 0.25 kW pump big enough to drain my pit?

It suits small to mid-size jobs. At its duty point of 9 m3/h at 3.0 m it clears a pit steadily, and the maximum head is 8 m, so keep the vertical lift and hose run well inside that figure. If you need more volume or more lift, step up to a larger pump in the same range.

Do I need a starter for the 0.25 kW three-phase pump?

Yes. Run it through a motor starter with overload protection, wired by a qualified electrician, and check the direction of rotation before you submerge it. It needs a 380 V to 415 V three-phase supply, so if you only have single-phase power choose the 220 V version instead.

Do you deliver a submersible pump to Welkom?

Yes. Kamano delivers with its own trucks from Polokwane to Welkom and all nine provinces in 1 to 3 days. At about 8 kg shipping weight this item falls in the up to 30 kg (R550) band, and orders of R20,000 or more (VAT incl.) go free. Add a hose and fittings to the same order.
