Spring loaded brass check valve, one-way non-return valve for pumps, sizes 15 to 40 mm

Spring Loaded Brass Check Valve, 15 to 40 mm

SKU KMN-FITG-0043

A spring loaded brass non-return valve that stops backflow to pumps and tanks, in five sizes from 15 mm to 40 mm, delivered across South Africa.

Price range: R78,00 through R404,00

Lets water flow one way and blocks reverse flow
Spring-operated brass valve protects pumps
Five sizes, 15 mm to 40 mm
From R 78, VAT incl.

MM Sizes

Clear

Request Bulk Quote Ask on WhatsApp

Delivered by our own trucks in 1 to 3 days. R550 / R950 / R1,450 by order weight. FREE on orders of R20,000 or more with code KH027. Delivery details

Specifications

Type	Spring loaded check valve (non-return)
Size	15, 20, 25, 32 or 40 mm, by option
Material	Brass
Mechanism	Spring operated
Flow	One direction, automatic shut-off on reverse
Use	Pumps, storage, irrigation, distribution
Product code	10047-1-2-1-1-1
Net weight	0.75 kg (40 mm option)
Shipping weight	0.9 kg
Dimensions	110 x 70 x 70 mm

Description

Overview

This spring loaded brass check valve is a one-way valve that lets water through in the flow direction and shuts automatically when flow reverses. It protects pumps from backflow, helps hold pressure in the line and cuts pressure fluctuations that waste energy.

The spring-operated mechanism responds quickly to pressure change, and the brass body resists corrosion. It works on high-pressure and low-pressure systems and is commonly fitted on household pressure pump set-ups, storage systems, irrigation and distribution networks.

Key features

Brass construction
Spring-operated one-way valve
Prevents reverse flow
Protects pumps and water systems
Corrosion resistant
Automatic operation, nothing to adjust
Suits high and low pressure

Options

Choose the size. Prices include VAT.

15 mm: R 78
20 mm: R 115
25 mm: R 151
32 mm: R 253
40 mm: R 404

Where it works

Fit it on the suction or discharge of a household pressure pump, on borehole installations in Limpopo and the Northern Cape, at the outlet of tanks, and in irrigation and commercial water distribution. A check valve in the line stops the pipe draining back to the borehole after the pump switches off. Seal the threads with PTFE thread seal tape and add a single union ball valve beside it so you can isolate it for servicing. See pipe fittings for the full range.

What’s in the box

1 x spring loaded brass check valve, selected size

Delivery and warranty

Kamano delivers with its own trucks from Polokwane to all nine provinces in 1 to 3 days, including Johannesburg, Upington, Kimberley, Bloemfontein, Pretoria and Mahikeng. The 40 mm valve ships at about 0.9 kg, well inside the R550 band for orders up to 30 kg. Delivery is free on orders of R20,000 or more (VAT incl.). Ask us for the warranty terms on this model.

Questions about this product

Which way round do I fit it?

With the flow arrow, or the open end of the spring side, pointing the way the water should travel. If it is fitted backwards the pump will not deliver, so check the body marking before tightening.

Can I use it on a borehole pump?

The supplier lists borehole installations as a typical use. It stops the column draining back when the pump stops. Check the size against your pump outlet.

Do you deliver to Upington?

Yes, in 1 to 3 days from Polokwane. The 40 mm valve is under 1 kg shipped, so it falls in the R550 band for orders up to 30 kg. Orders of R20,000 or more (VAT incl.) ship free.
