1.5 inch cast aluminium double poppet shear valve, ATEX marked

Shear Valve, 1.5″ Double Poppet, ATEX Marked

Name: Shear Valve, 1.5" Double Poppet, ATEX Marked
SKU: KMN-VALV-0011
Price: 1370.25 ZAR
Availability: InStock

SKU KMN-VALV-0011

A 1.5" cast aluminium double poppet shear valve marked ATEX by the supplier, for fuel outlets on bowsers and tankers, delivered nationwide.

R1 370,25

1.5″ double poppet shear (impact) valve
Cast aluminium body, stainless steel shaft
Shear force 600 to 880 N
ATEX marking stated by supplier

Delivered by our own trucks in 1 to 3 days. R550 / R950 / R1,450 by order weight. FREE on orders of R20,000 or more with code KH027. Delivery details

Specifications

Valve type	Shear (impact) valve, double poppet
Size	1.5" female inlet and outlet
Body material	Cast aluminium, stainless steel shaft
Seals	Viton or Buna-N
Shear force	600 to 880 N
Operating temperature	-25 to +55 C
Max pressure	Not stated by supplier, ask us
Certification (as stated by supplier)	ATEX IEP 13 ATEX 0153, EN 13617-3, EN 13463-5
Model code	S/A-DN40
Net weight	2.1 kg
Shipping weight	2.7 kg
Dimensions	110 × 80 × 130 mm

Description

Overview

This 1.5 inch shear valve is a double poppet shear (impact) valve for the outlet of a fuel bowser or tanker, designed so that the poppets close if the valve is struck and sheared, which holds the product in the tank.

The body is cast aluminium with a stainless steel shaft and Viton or Buna-N seals, with female 1.5 inch ports. The shear force is 600 to 880 N, the operating range is -25 to +55 C and the model code is S/A-DN40. The supplier states the certification as ATEX IEP 13 ATEX 0153, EN 13617-3 and EN 13463-5. Ask us for the certificate if your site requires it.

Key features

Double poppet design closes both sides on impact
Cast aluminium body with stainless steel shaft
Female 1.5 inch inlet and outlet
Operating range -25 to +55 C

Where it works

Fuel bowsers working on Limpopo farms, Mpumalanga coal mines and Gauteng depots fit a shear valve at the outlet, so a vehicle moving off with a hose attached cannot pull the tank apart. Buyers wanting a shear valve 1.5 inch ATEX version for a regulated site should check the certificate against site rules. See our valves and chemical handling equipment, and compare the 2″ angle check valve and the 3″ vapour recovery valve.

What’s in the box

1 x 1.5″ double poppet shear valve

Delivery and warranty

Kamano delivers with its own trucks from Polokwane to all nine provinces in 1 to 3 days, and delivery is free on orders of R20,000 or more (VAT incl.). At 2.7 kg shipping weight it falls in our up to 30 kg band (R550) of order weight. Order your shear valve 1.5 inch atex online and we confirm the delivery cost before dispatch.

Ask us for the warranty terms on this model.

Questions about this product

What does a shear valve do?

A shear valve fits at a tank or bowser outlet and is built to break at a set point if hit, for example by a vehicle driving off with the hose connected. The double poppets then close the tank side, so the product stays in. This valve has a shear force of 600 to 880 N.

Is this valve ATEX approved?

The supplier states the marking and standards as ATEX IEP 13 ATEX 0153, EN 13617-3 and EN 13463-5. We pass that on as stated by the supplier and have not tested it ourselves. If your site needs the certificate on file, ask us and we will request it before you order.

What seals and ports does it have?

It has female 1.5 inch inlet and outlet ports, a cast aluminium body, a stainless steel shaft and Viton or Buna-N seals. The operating temperature range is -25 to +55 C. The thread type is not stated by the supplier, so tell us what you need to connect and we will confirm.

Do you deliver a shear valve to Rustenburg or other towns outside Gauteng?

Yes. Kamano delivers with its own trucks from Polokwane to all nine provinces in 1 to 3 days. At 2.7 kg shipping weight this item falls in our up to 30 kg band at R550, or free if your order reaches R20,000 (VAT incl.). Fees are charged on total order weight, so combining items can lower the cost per item.
