FM120 1″ Mechanical Flowmeter, 20 to 120 L/min, 4 + 8 Digit Register

Description

Overview

The FM120 is a 1″ mechanical flowmeter for diesel and light oils with a 4-digit resettable batch counter and an 8-digit cumulative total. It measures from 20 to 120 L/min, has an aluminium and plastic body, and is rated to 3.5 bar. The register is driven by the fuel itself, so there are no batteries or cables.

The 8-digit total is useful when you want to reconcile months of issues against deliveries without the count rolling over. Reset the 4-digit batch before each fill to read litres per vehicle. Typical accuracy is around ±1% once calibrated on site. Fit it after a filter to protect the measuring chamber, and mount it where the driver can read the counter without climbing onto the trailer. It is a plain, honest meter that farmhands and drivers understand at a glance.

Key features

• 4-digit resettable batch counter
• 8-digit cumulative total that does not reset
• 20 to 120 L/min flow range
• 1″ connection for standard diesel pumps and hose
• Aluminium and plastic body rated to 3.5 bar

Where it works

This mechanical flowmeter suits farm tanks in the Free State and Limpopo, bakkie bowsers that stand in the veld for weeks, and municipal depots that want a meter with nothing electronic to fail. If you prefer the meter in the nozzle, see the analogue flowmeter nozzle; for a cheaper turbine option, the FM-TEM turbine flowmeter. More in our fuel flowmeters range.

What’s in the box

• 1 × FM120 mechanical flowmeter

Delivery and warranty

Kamano delivers with its own trucks from Polokwane to all nine provinces, normally in 1 to 3 days. This item ships at 1.8 kg, which puts it in the up-to-30 kg band at R550. Orders of R20,000 or more (VAT incl.) travel free, so it pays to combine it with a bigger order. Ask us for the warranty terms on this model.
