FM900 1″ Mechanical Diesel Flowmeter, Battery-Free Counter

Description

Overview

The FM900 is a diesel flow meter 1 inch in bore with a mechanical roller register, so it counts litres without batteries or wiring. The flowing fuel turns the element, and gears drive a resettable batch counter and a cumulative total.

Most 12V, 24V and 230V transfer pumps in South Africa have 1″ outlets, so this meter threads on directly with a nipple and goes to work. It is the same body as the 1.5″ FM900, simply with smaller ports. Mount it with the flow arrow pointing away from the pump and keep the hose full for the best reading.

Key features

• 1″ female threaded ports to suit standard transfer pumps
• Mechanical roller counter with a hand reset
• Cumulative total that cannot be zeroed
• Aluminium and engineering plastic body
• Covers 20-120 L/min at about ±1%

Where it works

This diesel flow meter 1 inch size is what most farm tanks and bakkie transfer kits use. Fit it to the pump on a 2,500 litre farm tank near Mokopane, on a skid unit in a contractor’s bakkie, or on the standby tank at a Limpopo game lodge to track generator use through load-shedding. If you later want a digital output for a fuel system, the FM-600 pulser flowmeter is the step up, and the FM600 digital oval gear flowmeter gives tighter accuracy. Compare the full range of diesel flowmeters.

What’s in the box

• FM900 mechanical diesel flowmeter with 1″ ports

Delivery and warranty

Kamano delivers with its own trucks from Polokwane to all nine provinces in 1 to 3 days. The FM900 1″ meter ships at about 3.3 kg, which puts it in the up to 30 kg band (R550). Delivery is free on orders of R20,000 or more, so it is worth adding the rest of your fuel kit to the same order. Ask us for the warranty terms on this model.
