DL20-100 vertical multistage pump wet end, 11kW, 28 m³/h, 136 m head

DL20-100 Vertical Multistage Pump Wet End, 11kW, 136 m Head

Name: DL20-100 Vertical Multistage Pump Wet End, 11kW, 136 m Head
SKU: KMN-PUMP-0212
Price: 21759.00 ZAR
Availability: InStock

SKU KMN-PUMP-0212

A 11 kW class vertical multistage pump wet end for boosting and water supply, up to 28 m³/h and 136 m head, delivered across South Africa from Polokwane.

R21 759,00

Up to 28 m³/h and 136 m head
10-stage vertical design, stainless steel impeller stack
11 kW, 3 phase 380 V rated, motor sold separately
R 21,759 VAT incl., delivered from Polokwane

Delivered by our own trucks in 1 to 3 days. R550 / R950 / R1,450 by order weight. FREE on orders of R20,000 or more with code KH027. Delivery details

Specifications

Model	DL20-100
Type	Vertical multistage centrifugal pump, wet end only
Stages	10
Maximum flow rate	28 m³/h (467 L/min)
Maximum head	136 m
Rated motor power	11 kW (motor sold separately)
Voltage / phase	3 phase, 380 V, 50 Hz (220 V and 525 V motor options available)
Inlet / outlet	On request
Self-priming	No
Fluid compatibility	Clean water
Construction	Stainless steel impeller stack
Motor included	No
Net weight	40 kg
Shipping weight	44 kg
Dimensions	280 x 220 x 870 mm

Description

Overview

The DL20-100 11 kW vertical multistage pump delivers up to 28 m³/h (467 L/min) and up to 136 m of head from a 10-stage stainless steel impeller stack.

This Kamano listing is for the pump wet end only. The motor is sold separately, so you choose the voltage and enclosure that suit your site. The range is built around a 11 kW three-phase 380 V, 50 Hz motor, with 220 V and 525 V motor options available. Ask us for a complete pump and motor package quote sized to your supply and duty.

Up to 136 m of head puts this 10-stage pump in the middle of the DL20 range. That suits long uphill pipelines, tall buildings and pressure-hungry irrigation or reverse osmosis duty. Maximum flow and maximum head do not occur together, so check your required duty point against the pump curve before you order.

Key features

Flow of up to 28 m³/h and head of up to 136 m
10 stages in a stainless steel impeller stack
Rated motor power of 11 kW, motor not included
Vertical multistage centrifugal design with a compact footprint
Three-phase 380 V, 50 Hz, with 220 V and 525 V motor options

Where it works

Typical jobs in Mpumalanga include commercial building pressure boosting, reverse osmosis feed water, large irrigation schemes and long industrial water lines. At this head it is also used where pressure must overcome elevation, such as hillside farms and mine surface water lines. A DL20-100 multistage pump suits these jobs well. If this size is not quite right, compare the DL20-120 15kW Vertical Multistage Pump or the DL20 Replacement Hydraulic Stack (Pump Cartridge), or browse all our multistage pumps.

What’s in the box

1 x DL20-100 vertical multistage pump wet end with stainless steel impeller stack
Motor not included: sold separately
Pipework, fittings and controller not included

Delivery and warranty

Kamano delivers with its own trucks from Polokwane to all nine provinces in 1 to 3 days, including Pietermaritzburg, Tzaneen, Klerksdorp, Durban and Mbombela. This DL20-100 multistage pump ships at about 44 kg boxed, which falls in the R950 delivery band. Delivery is charged by total order weight: up to 30 kg R550, 30 to 60 kg R950, 60 to 100 kg R1,450, and over 100 kg on quotation. At R 21,759 this pump also qualifies for free delivery on its own. Orders of R20,000 or more are delivered free (VAT incl.). Ask us for the warranty terms on this model.

Questions about this product

Does the DL20-100 come with a motor?

No. Kamano lists the DL20-100 as a wet end only, so the 11 kW motor is sold separately. The range is built around 3 phase, 380 V, 50 Hz motors, and 220 V or 525 V options exist. Tell us your supply voltage and we will quote a complete pump and motor package.

What flow and pressure will I get from the DL20-100?

Up to 28 m³/h and up to 136 m of head. Those are separate maximums, so real flow falls as pressure rises along the pump curve. Give us your required flow, pipe length and height lift, and we will confirm whether the DL20-100 suits, or whether another DL20 size is a better fit.

Do you deliver the DL20-100 to Pietermaritzburg?

Yes. Kamano delivers with its own trucks from Polokwane to all nine provinces, usually in 1 to 3 days, and Pietermaritzburg is covered. At about 44 kg boxed this pump sits in the R950 delivery band, and orders of R20,000 or more are delivered free (VAT incl.).

What is the DL20-100 used for?

High-head duty: tall buildings, long uphill lines, large irrigation and reverse osmosis feed. Give us your flow, pipe length and lift and we will confirm the size.

Nationwide delivery from Polokwane

Delivered to all nine provinces in 1 to 3 days

We deliver the DL20-100 Vertical Multistage Pump Wet End, 11kW, 136 m Head with our own trucks to Johannesburg, Pretoria, Cape Town, Durban, Gqeberha, Bloemfontein, Polokwane, Mbombela, Rustenburg, Tzaneen, Mahikeng, eMalahleni, George and Pietermaritzburg, and to farms, mines and sites in between. This item ships in the R950 delivery band (30 to 60 kg). Orders of R20,000 or more deliver free with code KH027.
