DL1 replacement hydraulic stack cartridge for vertical multistage pumps, DL1-50 to DL1-270

DL1 Replacement Hydraulic Stack, DL1-50 to DL1-270, by Model

SKU KMN-PUMP-0014

A complete replacement hydraulic stack for DL1 vertical multistage pumps, matched to your exact model and delivered across South Africa.

Price range: R3 120,00 through R13 776,00

Restores a worn DL1 pump to its original pressure and flow
Complete cartridge for the model you select, DL1-50 to DL1-270
Re-uses your motor, base and outer sleeve
From R 3,120 (VAT incl.)

Pump model

Clear

Request Bulk Quote Ask on WhatsApp

Delivered by our own trucks in 1 to 3 days. R550 / R950 / R1,450 by order weight. FREE on orders of R20,000 or more with code KH027. Delivery details

Specifications

Fits pumps	DL1 vertical multistage pumps, DL1-50 to DL1-270
Supplied as	Complete cartridge stack for the selected model
Stages	5 to 27 stages, by option
Motor rating	0.37 kW to 1.5 kW, by option
Stack codes	95020246 to 95020261, plus 95020165 for DL1-80
Mechanical seal	Sold separately, code 95020136
Re-used parts	Motor, base and outer sleeve
Price	From R 3,120 (VAT incl.), by option
Net weight	3.5 kg
Shipping weight	5 kg
Dimensions	700 x 70 x 70 mm

Description

Overview

This replacement hydraulic stack is the complete cartridge of impellers, stage chambers (diffusers) and shaft for a DL1 vertical multistage pump, supplied for the exact model you select. It restores a worn pump to its original pressure and flow for much less than a new pump, because the motor, base and outer sleeve are re-used.

Sand, grit and running dry wear the impellers, and the pump loses pressure and flow. Read the model on your nameplate, for example DL1-130. The number after the dash gives the stages (-40 is 4 stages), and the stack must match exactly. Send us a photo of the nameplate and we will confirm the part.

Replace the seal at the same time: see the DL1, DL3 and DL5 cartridge mechanical seal (code 95020136, sold separately), or browse the multistage pump range.

Key features

Complete cartridge for the DL1 model you select
17 models, 0.37 kW to 1.5 kW
Re-uses your motor, base and outer sleeve

Options

Each option is the stack for one DL1 model, VAT incl.

DL1-50 (0.37 kW), code 95020246: R 3,120
DL1-60 (0.37 kW), code 95020247: R 3,544
DL1-70 (0.37 kW), code 95020248: R 3,968
DL1-80 (0.55 kW), code 95020165: R 4,448
DL1-90 (0.55 kW), code 95020249: R 4,832
DL1-100 (0.55 kW), code 95020250: R 5,264
DL1-110 (0.55 kW), code 95020251: R 6,272
DL1-120 (0.75 kW), code 95020252: R 6,704
DL1-130 (0.75 kW), code 95020253: R 7,136
DL1-140 (0.75 kW), code 95020254: R 7,568
DL1-150 (0.75 kW), code 95020255: R 8,000
DL1-170 (1.1 kW), code 95020256: R 8,856
DL1-190 (1.1 kW), code 95020257: R 9,720
DL1-210 (1.1 kW), code 95020258: R 10,600
DL1-230 (1.1 kW), code 95020259: R 12,032
DL1-250 (1.5 kW), code 95020260: R 12,896
DL1-270 (1.5 kW), code 95020261: R 13,776

Where it works

DL1 pumps boost pressure for homes, lodges, garden irrigation and small farm water schemes in Limpopo, Gauteng and KwaZulu-Natal. See also the DL1-100 vertical multistage pump.

What’s in the box

1 x hydraulic stack (cartridge) for the model selected
Mechanical seal not included

Delivery and warranty

Kamano delivers with its own trucks from Polokwane to all nine provinces in 1 to 3 days, with regular runs to Cape Town, Durban, Mahikeng, Welkom, Upington and Richards Bay. The heaviest option ships at about 5 kg, in the up to 30 kg delivery band (R550). Free delivery applies to orders of R20,000 or more (VAT incl.). Ask us for the warranty terms on this model.

Questions about this product

How do I choose the right DL1 stack?

Read the model on your pump nameplate, for example DL1-130, and pick the same model from the options. The number after the dash gives the stages, and the stack must match exactly or it will not fit the sleeve or give the right pressure. Send us a photo of the nameplate and we will confirm the part.

Is the mechanical seal included with the stack?

No. The stack is supplied alone and the seal is sold separately as code 95020136, which fits DL1, DL3 and DL5 pumps. We recommend fitting a new seal whenever you replace the stack, and never running the pump dry, because a dry run of a few minutes can burn the seal faces.

Do you deliver a DL1 stack to Welkom?

Yes, we deliver to Welkom and all nine provinces with our own trucks from Polokwane in 1 to 3 days. The heaviest stack ships at about 5 kg. That falls in the up to 30 kg delivery band (R550). Free delivery applies to orders of R20,000 or more (VAT incl.).
