Replacement hydraulic stack cartridge for DL8 vertical multistage pumps, DL8-20 to DL8-200

DL8 Replacement Hydraulic Stack (Pump Cartridge), DL8-20 to DL8-200

SKU KMN-PUMP-0011

Replacement hydraulic stack for DL8 vertical multistage pumps, from DL8-20 to DL8-200, delivered across South Africa from Polokwane.

Price range: R4 208,00 through R23 696,00

Restores a worn DL8 pump to its original pressure and flow
Fits DL8-20 (0.75 kW) to DL8-200 (7.5 kW)
Complete cartridge: impellers, stage chambers and shaft
Mechanical seal sold separately

Pump model

Clear

Request Bulk Quote Ask on WhatsApp

Delivered by our own trucks in 1 to 3 days. R550 / R950 / R1,450 by order weight. FREE on orders of R20,000 or more with code KH027. Delivery details

Specifications

Fits	DL8 vertical multistage pumps, DL8-20 to DL8-200
Flow rate	As per the pump model selected
Max head / pressure	As per the pump model selected
Voltage / phase	Not applicable (hydraulic part, no motor)
Power	0.75 kW to 7.5 kW pumps, by option
Inlet / outlet	Not applicable (re-uses the existing sleeve and base)
Self-priming	No (needs flooded suction)
Duty cycle	On request
Fluid compatibility	Water
Supplied as	Complete cartridge stack for the model selected
Mechanical seal	Sold separately, code 95020103 (fits DL8, DL12, DL16, DL20)
Net weight	12 kg
Shipping weight	14 kg
Dimensions	950 × 110 × 110 mm

Description

Overview

This is the complete replacement hydraulic stack for DL8 vertical multistage pumps, from DL8-20 to DL8-200. The stack is the heart of the pump: the impellers, stage chambers (diffusers) and shaft that build pressure. Sand, grit or running dry wears it, and the pump loses pressure and flow.

A new stack restores original performance for much less than a new pump, because the motor, base and outer sleeve are re-used. For a bigger duty, see the DL64-20 11 kW multistage pump or the DL64-30 18.5 kW multistage pump.

Key features

Complete cartridge stack for the DL8 model you select.
The number after the dash is the stage count (-40 is four stages), and the stack must match it exactly.
Mechanical seal sold separately. We recommend replacing it at the same time: code 95020103 fits DL8, DL12, DL16 and DL20.
Unsure of your model? Send a photo of the nameplate and we will confirm the part.

Options

Pick the model on your nameplate. Prices are VAT incl.

DL8-20 (0.75 kW): code 95020299, R 4,208
DL8-30 (1.1 kW): code 95020060, R 5,176
DL8-40 (1.5 kW): code 95020062, R 6,144
DL8-50 (2.2 kW): code 95020300, R 7,120
DL8-60 (2.2 kW): code 95020301, R 8,088
DL8-70 (3 kW): code 95020302, R 9,056
DL8-80 (3 kW): code 95020303, R 10,024
DL8-90 (3 kW): code 95020304, R 11,920
DL8-100 (4 kW): code 95020305, R 12,904
DL8-110 (4 kW): code 95020306, R 13,880
DL8-120 (4 kW): code 95020307, R 14,856
DL8-130 (5.5 kW): code 95020308, R 15,840
DL8-140 (5.5 kW): code 95020309, R 16,832
DL8-150 (5.5 kW): code 95020310, R 18,736
DL8-160 (5.5 kW): code 95020311, R 19,728
DL8-170 (7.5 kW): code 95020312, R 20,712
DL8-180 (7.5 kW): code 95020313, R 21,704
DL8-190 (7.5 kW): code 95020314, R 22,696
DL8-200 (7.5 kW): code 95020166, R 23,696

Where it works

A new stack suits any DL8 that has lost pressure on borehole boosting, irrigation or building water supply, from Limpopo farms to Gauteng workshops.

What’s in the box

Hydraulic stack (cartridge) for the selected DL8 model
Mechanical seal not included

Delivery and warranty

Kamano delivers with its own trucks from Polokwane to all nine provinces in 1 to 3 days, including Rustenburg, Johannesburg, Bloemfontein, Mbombela, Cape Town and Tzaneen. A stack ships at about 14 kg, in our up to 30 kg band (R550), and orders of R20,000 VAT incl. or more get free delivery. Browse the full multistage pumps range. Ask us for the warranty terms on this model.

Questions about this product

How do I choose the right DL8 stack?

Read the model on your pump nameplate, for example DL8-110. The number after the dash tells you the stage count, and the stack must match it exactly. A stack with a different number of stages will not fit the sleeve or give the right pressure. Send us a photo of the nameplate and we will confirm the part.

Should I replace the mechanical seal too?

Yes, we recommend it. The seal is sold separately under code 95020103 and fits DL8, DL12, DL16 and DL20 pumps. Fitting a new seal while the pump is already apart costs little and avoids opening it again soon. Ask us to quote the seal and stack together.

Is it cheaper than buying a new pump?

Usually, yes. The stack is the part that wears, and the motor, base and outer sleeve are re-used. Prices run from R 4,208 for the DL8-20 to R 23,696 for the DL8-200. If the motor or sleeve is also damaged, a new pump may make more sense.

Do you deliver a DL8 stack to Rustenburg?

Yes. Kamano delivers from Polokwane with its own trucks to all nine provinces, normally within 1 to 3 days, including Rustenburg. A stack ships at about 14 kg, in our up to 30 kg band (R550). Orders from R20,000 VAT incl. get free delivery.
