Replacement hydraulic stack pump cartridge for DL16 vertical multistage pumps, DL16-20 to DL16-160

DL16 Replacement Hydraulic Stack (Pump Cartridge), DL16-20 to DL16-160

SKU KMN-PUMP-0009

A complete replacement hydraulic stack for DL16 vertical multistage pumps, in 15 model sizes, delivered nationwide from Polokwane.

Price range: R4 272,00 through R21 760,00

Restores a worn DL16 pump to its original pressure and flow
Complete cartridge of impellers, stage chambers and shaft
Choose the stack that matches your nameplate model
Motor, base and outer sleeve are re-used

Pump model

Clear

Request Bulk Quote Ask on WhatsApp

Delivered by our own trucks in 1 to 3 days. R550 / R950 / R1,450 by order weight. FREE on orders of R20,000 or more with code KH027. Delivery details

Specifications

Fits	AQS DL16 vertical multistage pumps, DL16-20 to DL16-160
Part type	Complete hydraulic stack (impellers, stage chambers, shaft)
Stage count	Number after the dash divided by 10 (DL16-40 has 4 stages)
Re-used parts	Motor, base and outer sleeve
Mechanical seal	Sold separately, code 95020103 (fits DL8, DL12, DL16 and DL20)
Stack codes	95020168 (DL16-20) to 95020164 (DL16-160), see Options
Motor power by model	2.2 kW (DL16-20) to 15 kW (DL16-150 and DL16-160)
Flow rate	N/A (spare part)
Self-priming	N/A (spare part)
Net weight	16 kg (heaviest option, DL16-160)
Shipping weight	18 kg
Dimensions	1100 x 110 x 110 mm

Description

Overview

This is a complete replacement hydraulic stack, also called a pump cartridge, for DL16 vertical multistage pumps. The stack is the heart of the pump: the impellers, stage chambers (diffusers) and shaft that build pressure. Sand, grit or running dry wears the impellers until the pump loses pressure and flow. Fitting a new stack restores the original performance for much less than a new pump, because the motor, base and outer sleeve are re-used. See the multistage pumps category, or the DL16-100 pump end and DL16-150 pump end.

Key features

Supplied as a complete cartridge stack for the model you select
Fits the DL16 range, from DL16-20 to DL16-160
Brings a sand-worn or dry-run pump back to full pressure
The mechanical seal is sold separately (code 95020103, fits DL8, DL12, DL16 and DL20), and we recommend replacing it at the same time

Options

Read the model on your pump nameplate, for example DL16-90. The number after the dash gives the stage count (-40 means 4 stages), and the stack must match exactly or it will not fit the sleeve. Prices are VAT incl.

DL16-20 (2.2 kW), code 95020168: R 4,272
DL16-30 (3 kW), code 95020110: R 5,464
DL16-40 (4 kW), code 95020170: R 6,640
DL16-50 (4 kW), code 95020171: R 7,816
DL16-60 (5.5 kW), code 95020172: R 9,912
DL16-70 (5.5 kW), code 95020326: R 10,168
DL16-80 (7.5 kW), code 95020327: R 11,344
DL16-90 (7.5 kW), code 95020328: R 12,304
DL16-100 (11 kW), code 95020173: R 14,624
DL16-110 (11 kW), code 95020329: R 15,552
DL16-120 (11 kW), code 95020139: R 16,984
DL16-130 (11 kW), code 95020330: R 18,960
DL16-140 (11 kW), code 95020331: R 19,368
DL16-150 (15 kW), code 95020332: R 21,336
DL16-160 (15 kW), code 95020164: R 21,760

Where it works

Use it on any DL16 pump that has lost performance from wear: borehole boosters in Limpopo, irrigation sets in the Free State, or building pressure systems in Gauteng. Not sure which stack you need? Send us a photo of the nameplate and we will confirm the part.

What’s in the box

Hydraulic stack (pump cartridge) for the selected model

Delivery and warranty

Kamano delivers with its own trucks from Polokwane to all nine provinces in 1 to 3 days, including Johannesburg, Pretoria, Cape Town, Bloemfontein, Durban and Rustenburg. The largest stack ships at about 18 kg, in the up to 30 kg band at R550. Fees are set by total order weight: 30 to 60 kg R950, 60 to 100 kg R1,450, over 100 kg on quotation. Orders of R20,000 or more (VAT incl.) are delivered free. Ask us for the warranty terms on this part.

Questions about this product

How do I choose the right DL16 stack?

Read the model on your pump nameplate, for example DL16-90. The number after the dash gives the stage count, and the stack must match it exactly or it will not fit the sleeve. Pick the same model in the Options list. If you are unsure, send us a photo of the nameplate and we will confirm the part.

Do I need to replace the mechanical seal as well?

We recommend it. The seal is sold separately under code 95020103, which fits DL8, DL12, DL16 and DL20 pumps. Changing it while the pump is apart avoids a second strip-down later. Ask us to add it to your order.

Do you deliver the DL16 stack to Cape Town?

Yes. Kamano delivers with its own trucks from Polokwane to all nine provinces in 1 to 3 days, Cape Town included. Even the largest stack is about 18 kg, so delivery is R550 in the up to 30 kg band. Orders of R20,000 or more (VAT incl.) ship free.
