25 mm Compact PVC Ball Valve, BSP Threaded, 16 bar, CBV25MMT

Description

Overview

The 25 mm compact PVC ball valve suits 1 inch plumbing, the size of many borehole pump outlets, pressure pump set-ups and irrigation sub-mains. It has BSP threads and a quarter-turn handle, and is rated to a maximum of 16 bar.

The plastic body does not rust and is light enough to hang off a manifold without extra support. Put one on each branch and you can isolate a filter, pump or sprinkler block without shutting down the rest.

Key features

• 25 mm BSP threaded connections
• Compact PVC body
• Quarter-turn operation
• Maximum pressure 16 bar
• Does not rust
• Model code CBV25MMT, barcode 6009507886678

Where it works

Fit it at a borehole headworks in Limpopo or the Northern Cape, at a pump discharge on a Free State farm, ahead of a filter bank in a KwaZulu-Natal nursery, or on a pool plant room line. Use PTFE tape from our thread seal tape pack on the male thread and take care not to crack the plastic by overtightening. If you need the next size up see the 32 mm compact ball valve, and for a metal check valve on the same line the spring loaded brass check valve. More options are in pipe fittings.

What’s in the box

• 1 x 25 mm compact PVC ball valve, BSP threaded

Delivery and warranty

Kamano delivers with its own trucks from Polokwane to all nine provinces in 1 to 3 days, including Pretoria, Upington, Kimberley, Mahikeng, East London and George. A valve ships at about 0.1 kg, so it sits in the lowest delivery band (R550 for orders up to 30 kg). Delivery is free on orders of R20,000 or more (VAT incl.). Ask us for the warranty terms on this model.
