1.5 inch cast iron angle check valve with brass top and Buna-N seals

Angle Check Valve, 1.5″ Cast Iron, Buna-N Seals

Name: Angle Check Valve, 1.5" Cast Iron, Buna-N Seals
SKU: KMN-VALV-0001
Price: 1124.55 ZAR
Availability: InStock

SKU KMN-VALV-0001

A 1.5" cast iron angle check valve with Buna-N seals for fuel suction lines, delivered by Kamano to farms, depots and forecourts nationwide.

R1 124,55

One-way angle check valve for fuel suction lines
1.5″ inlet and outlet, cast iron body
Buna-N (nitrile) seals
Model code CH005

Delivered by our own trucks in 1 to 3 days. R550 / R950 / R1,450 by order weight. FREE on orders of R20,000 or more with code KH027. Delivery details

Specifications

Valve type	Angle check (non-return) valve
Size	1.5" inlet and outlet
Body material	Cast iron
Seals	Buna-N (nitrile)
Connection / thread	On request
Max pressure	Not stated by supplier, ask us
Fluid compatibility	Fuel suction service, ask us about other liquids
Model code	CH005
Net weight	3 kg
Shipping weight	4 kg
Dimensions	120 × 80 × 130 mm

Description

Overview

This 1.5 inch angle check valve is a one-way valve for fuel suction lines: product flows towards the pump, and the valve closes when flow stops so the line stays full and the pump keeps its prime.

The body is cast iron with Buna-N (nitrile) seals, and the angle pattern turns the line through a bend, which saves an elbow fitting in tight pipework. The supplier does not state a pressure rating, so ask us before using it on a pressurised line. Model code CH005.

Key features

Cast iron body with Buna-N seals for fuel service
Angle pattern replaces a separate elbow
Holds the suction line full between pumping cycles
1.5″ inlet and outlet

Where it works

On a farm diesel tank, a depot bowser or a forecourt suction run, the valve sits between the tank outlet and the pump so the line does not drain back overnight. Limpopo and Mpumalanga fleet yards use one to keep pumps primed after load-shedding stops a shift. See more in our valves and chemical handling equipment, and consider the 1.5″ double poppet shear valve and the ATEX marked shear valve for the outlet side of the same installation. Anyone searching for an angle check valve 1.5 inch for diesel will find this the right size.

What’s in the box

1 x 1.5″ angle check valve

Delivery and warranty

Kamano delivers with its own trucks from Polokwane to all nine provinces in 1 to 3 days, and delivery is free on orders of R20,000 or more (VAT incl.). At 4 kg shipping weight it falls in our up to 30 kg band (R550) of order weight. Order your angle check valve 1.5 inch online and we confirm the delivery cost before dispatch.

Ask us for the warranty terms on this model.

Questions about this product

What does an angle check valve do on a diesel suction line?

It lets fuel flow one way, from the tank towards the pump, and shuts against reverse flow. That keeps the suction line full so the pump does not run dry on start-up. The angle body also turns the pipe through a bend, so you can skip a separate elbow fitting in a tight installation.

What is the valve made of and what pressure can it take?

The body is cast iron and the seals are Buna-N (nitrile), which is the usual choice for diesel and petrol. The supplier does not state a pressure rating for this valve, so we have not guessed one. Tell us the working pressure of your line and we will confirm whether it suits.

What is the difference between the 1.5 inch and 2 inch versions?

Only the line size: both are cast iron with Buna-N seals and the same angle pattern. The 1.5 inch version is model CH005 and is the one to choose for 1.5 inch suction hose or pipe. The 2 inch valve is model CH007 and suits larger-bore lines with higher flow.

Do you deliver a 1.5 inch check valve to Rustenburg or other towns outside Gauteng?

Yes. Kamano delivers with its own trucks from Polokwane to all nine provinces in 1 to 3 days. At 4 kg shipping weight this item falls in our up to 30 kg band at R550, or free if your order reaches R20,000 (VAT incl.). Fees are charged on total order weight, so combining items can lower the cost per item.
