60 L Vertical Steel Pressure Tank, 8 Bar, 1″ Connection

Description

Overview

This 60 litre vertical pressure tank gives a booster pump a proper buffer of pressurised water, so the pump rests between demands instead of chasing every tap. A carbon steel shell holds an EPDM bladder that keeps the water away from the air cushion, and the tank is rated to 8 bar with a 1″ (25 mm) connection. It is one of the vertical vessels in our pump controllers and VSD accessories.

Bladder-type tanks like this one release stored water on demand and prevent pump start-ups for demands smaller than their storage volume. The bladder stops water touching the air or the steel, which protects the shell from corrosion on the inside.

Key features

• Capacity: 60 litres
• Carbon steel tank
• EPDM bladder, rated 0 to 99 degrees C
• Working pressure: 8 bar
• Vertical orientation
• Connection: 1″ / 25 mm
• Ambient temperature up to 45 degrees C

Where it works

Sixty litres suits a family home with two or three bathrooms, a farm homestead in Limpopo or the Free State, or a small irrigation line off a borehole booster. Mount it indoors or in a pump shed, out of direct sun, since the rating assumes an ambient temperature of 45 degrees C or lower. Installers often pair it with a pump protection controller from our range, such as the Y1 digital protection controller for 380 V pumps. For smaller systems look at the 24 L vertical steel pressure tank.

What’s in the box

• 1 x 60 L vertical carbon steel pressure tank with EPDM bladder

Delivery and warranty

Kamano delivers with its own trucks from Polokwane to all nine provinces in 1 to 3 days, including Polokwane, Tzaneen, Johannesburg, Pretoria, Mbombela, Bloemfontein and Kimberley. Fees are set by total order weight. At a shipping weight of about 11.5 kg this item falls in the up to 30 kg band (R550), and orders of R20,000 or more (VAT incl.) are delivered free.

Tank warranty: 1 to 2 years, depending on the model.
