1.5 kW Submersible Pump, 380 V Three-Phase, 50 mm Outlet

Description

Overview

The 1.5 kW (2 HP) three-phase WSD-series submersible, model WS28-18-1.5E, is a step up in lift for sites on 380 V to 415 V supply. It delivers 25 m3/h at 7.7 m and reaches 18.2 m at shut-off through a 50 mm outlet. The open channel impeller passes small solids, and the removable suction screen lets you run it on dirty water or screened sewage. It is compact enough for one person to lower into a sump on its 10 m cable. No float switch is listed with this version, so add level control and a motor starter.

Key features

• Three-phase motor, 380 V to 415 V
• Cast iron pump body and open vane impeller
• Double mechanical seal, graphite/ceramic and graphite/silicon carbide, nitrile elastomer
• Removable suction screen
• 10 m power cable, 5 m maximum immersion depth
• Handles liquid up to 40 °C at a density of 1 kg/l

Where it works

Use it to dewater foundations and trenches on Gauteng and Western Cape building sites, to empty dams and tailings sumps on Limpopo farms and mines, and to clear flooded plant rooms. Wire it to a starter with overload protection. The 1.5 kW 220 V submersible pump suits single-phase supply, and the 2.2 kW 380 V submersible pump gives more head again. Browse our submersible pumps.

What’s in the box

• 1.5 kW three-phase submersible pump, model WS28-18-1.5E
• Removable suction screen
• 10 m power cable

Delivery and warranty

Kamano delivers with its own trucks from Polokwane to all nine provinces in 1 to 3 days, with regular runs to Pretoria, Johannesburg, Cape Town, Polokwane, Klerksdorp and Upington. Fees are set by total order weight: up to 30 kg R550, 30 to 60 kg R950, 60 to 100 kg R1,450, and over 100 kg on quotation. At 17 kg shipping weight this pump sits in the up to 30 kg band at R550. Orders of R20,000 or more (VAT incl.) ship free. Ask us for the warranty terms on this model.
