SKD-11 Flow Switch, 0 to 15 m3/h, 1-1/4″ BSP, IP65

Description

Overview

The SKD-11 is a flow switch that sits in the pump discharge line and starts the pump when water begins to flow, then stops it when flow ceases. It handles flows from 0 to 15 m3/h and has 1-1/4 inch BSP connections at both ends, so it suits larger domestic and small farm pumps.

Because it reacts to flow, not to a pressure drop alone, it avoids the on and off cycling of a basic tank-and-switch set and helps protect a pump from running dry. It runs on 220 V AC at 50 Hz and switches up to 30 A. The IP65 rating keeps dust and splashes out, the starting pressure is 1.2 bar and the maximum working pressure is 10 bar.

For matching parts, see our pump controllers and VSD accessories.

Key features

• Flow range of 0 to 15 m3/h
• 1-1/4 inch BSP inlet and outlet
• Rated 220 V AC, 50 Hz, maximum current 30 A
• IP65 protection against dust and splashes
• Starting pressure 1.2 bar, maximum pressure 10 bar

Where it works

Use it on borehole and rainwater pumps at Limpopo farms, on household booster sets in Gauteng and KZN, and on garden irrigation pumps that start and stop with a tap. If the board fails, the SKD-11 replacement PC board is available separately. For smaller pumps, look at the 1 inch SKD-2 flow switch.

What’s in the box

• 1 x SKD-11 flow switch

Delivery and warranty

Kamano delivers with its own trucks from Polokwane to all nine provinces in 1 to 3 days, including Johannesburg, Pretoria, Polokwane, Durban, Pietermaritzburg, Cape Town and Bloemfontein. Shipping weight is 2 kg, so this item sits in the R550 (up to 30 kg) delivery band. Delivery fees are set by total order weight: up to 30 kg R550, 30 to 60 kg R950, 60 to 100 kg R1,450, and over 100 kg on quotation. Orders of R20,000 or more (VAT incl.) are delivered free.

Ask us for the warranty terms on this model.
