Polypropylene Camlock Type D Female Coupler x Female BSP, 15 to 50 mm

SKU KMN-FITG-0010

A polypropylene camlock Type D (female coupler x female bsp) in 15, 20, 25, 32, 40 and 50 mm, delivered across South Africa from Polokwane.

Price range: R45,00 through R99,00

Camlock Type D: female coupler x female bsp
Polypropylene body in 15, 20, 25, 32, 40 and 50 mm
Product codes TD015P to TD050P
From R 45 VAT incl.

Camlock Sizes

Clear

Request Bulk Quote Ask on WhatsApp

Delivered by our own trucks in 1 to 3 days. R550 / R950 / R1,450 by order weight. FREE on orders of R20,000 or more with code KH027. Delivery details

Specifications

Type	Type D female coupler x female bsp
Material	Polypropylene
Camlock end	Female camlock coupler with locking arms
Other end	Female BSP thread
Sizes	15, 20, 25, 32, 40 and 50 mm (by option)
Product codes	TD015P, TD020P, TD025P, TD032P, TD040P, TD050P
Mates with	Any male camlock adaptor of the same size
Max pressure	On request
Suitable for	Water, agricultural, industrial and chemical handling
Net weight	0.12 kg
Shipping weight	0.18 kg
Dimensions	95 x 80 x 80 mm

Description

Overview

The polypropylene camlock Type D has a female camlock coupler with locking arms on one end and a female BSP thread on the other. The thread screws onto a male-threaded pipe or nipple, and the coupler locks onto any male camlock adaptor of the same size.

Polypropylene resists corrosion, chemicals and weathering, and it is light and economical, so it suits agricultural, industrial, water and chemical handling duty. The straight-through design keeps the pipe diameter, so flow is not restricted. Browse the full pipe fittings range for the other camlock types.

Key features

Type D camlock: female coupler x female bsp
Sizes: 15, 20, 25, 32, 40 and 50 mm
Product codes TD015P to TD050P
Connects and disconnects by hand, no specialised tools
Corrosion, chemical and weather resistant polypropylene
Lightweight and cost-effective
Female thread screws onto male-threaded fittings

Options

Choose the size that matches your hose or pipe. Prices are per fitting and include VAT.

15 mm (code TD015P): R 45
20 mm (code TD020P): R 46
25 mm (code TD025P): R 51
32 mm (code TD032P): R 79
40 mm (code TD040P): R 82
50 mm (code TD050P): R 99

Where it works

Put it on male-threaded valve and pump outlets at Gqeberha packhouses, Eastern Cape irrigation set-ups and Northern Cape pump stations. Pair it with the Type A male adaptor on the opposite side, and cap an unused end with the Type DP male end cap.

What’s in the box

1 x polypropylene camlock Type D female coupler x female bsp (size as selected)

Delivery and warranty

Kamano delivers with its own trucks from Polokwane to all nine provinces in 1 to 3 days, including Gqeberha, East London, Kimberley, Upington, Bloemfontein and Polokwane. Shipping weight is about 0.18 kg. Delivery is charged by total order weight: up to 30 kg R550, 30 to 60 kg R950, 60 to 100 kg R1,450, and over 100 kg on quotation. Orders of R20,000 or more (VAT incl.) ship free. Ask us for the warranty terms on this model.

Questions about this product

When do I need a Type D instead of a Type B?

Choose the Type D when the part you are fitting to has a male thread, and the Type B when it has a female thread. Both give you a female camlock coupler on the free end, so the only difference is the thread gender at the other end.

Which thread standard does it use?

It has a BSP (British Standard Pipe) female thread, matching the BSP male threads used on most South African valves, taps and pump ports. Make sure the nominal size matches, and seal the male thread with PTFE tape before you screw the fitting on.

Which sizes and prices are available?

The Type D comes in 15, 20, 25, 32, 40 and 50 mm. Prices run from R 45 for the 15 mm size to R 99 for the 50 mm size, VAT incl., so pick your size from the options on this page. Each size has its own product code, which makes re-ordering easy.

Do you deliver to East London?

Yes. We deliver with our own trucks from Polokwane to East London and the rest of South Africa in 1 to 3 days. A single fitting weighs well under 1 kg, so it falls in the up to 30 kg band at R550, and orders of R20,000 or more ship free. Add other fittings to the same order to share the delivery fee.
