YB80 3 Inch Vane Transfer Pump Set, 1000 L/min, 7.5 kW 380V

Description

Overview

The YB80 is a 3 inch sliding-vane transfer pump set that moves up to 1000 L/min of diesel, paraffin or light lubricating oil. A 7.5 kW explosion-proof motor (YBX3-132M-4) with a gear reducer drives it from a 380V three-phase supply, all mounted as one set. It fits between the YB65 and the big YB100, and suits tanker offloading and mine bowser filling.

For the next size up, see the YB100 4 inch pump set. Servicing a YB80 later? The YB80 vane and repair kit holds the wear parts. All options are in fuel transfer pumps.

Key features

• Self-priming sliding-vane pump in nodular cast iron
• Built-in bypass and relief valve with replaceable vanes
• 7.5 kW explosion-proof motor, 380V three-phase 50 Hz, 15.4 A, IP55, continuous duty
• Working pressure 5 bar
• 3 inch BSP female inlet and outlet

Where it works

Coal mines in Mpumalanga and mining houses in the Northern Cape use a 1000 l/min diesel transfer pump like this to fill site bowsers and storage. Bulk depots in Gauteng and KZN offload road tankers with it, and large Free State grain operations use it for bulk diesel supply. It needs three-phase power.

What’s in the box

• YB80 3 inch sliding-vane pump
• 7.5 kW explosion-proof motor with gear reducer, mounted as a set

Delivery and warranty

Kamano delivers with its own trucks from Polokwane to all nine provinces in 1 to 3 days. Delivery is free on orders of R20,000 or more (VAT incl.). This set ships at 246 kg, which is over 100 kg, so delivery is on quotation. Ask us for the warranty terms on this model.
