DZA(S) 100-80-200 37kW stainless steel end-suction pump set with motor, 200 m³/h

DZA(S) 100-80-200 Stainless End-Suction Pump Set, 37kW, 200 m³/h, 63 m

SKU KMN-PUMP-0055

A 37kW stainless steel end-suction pump set for farms, buildings and industry, with a choice of motor voltage, delivered across South Africa.

R82 664,00

304 stainless steel pump end fitted to a 37kW (50HP) motor
Up to 200 m³/h (3333 L/min) and 63 m maximum head
100 mm suction and 80 mm delivery flanges
Choose 380V three-phase or 525V three-phase motor, from R 82,664 VAT incl.

Configuration

Clear

Request Bulk Quote Ask on WhatsApp

Delivered by our own trucks in 1 to 3 days. R550 / R950 / R1,450 by order weight. FREE on orders of R20,000 or more with code KH027. Delivery details

Specifications

Model	Vega DZA(S) 100-80-200
Model code	DZA-100-80-200-37-M
Pump type	End-suction centrifugal, flanged, complete set with motor
Material	304 stainless steel casing and impeller
Flow rate	Up to about 200 m³/h (3333 L/min)
Max head / pressure	63 m (about 6.3 bar with the valve closed)
Duty point	140 m³/h at 55 m (works best here)
Performance	0 m³/h at 63 m; 60 m³/h at 61 m; 100 m³/h at 59 m; 120 m³/h at 57 m; 140 m³/h at 55 m; 160 m³/h at 53 m; 180 m³/h at 50 m; 192 m³/h at 47 m; 200 m³/h at 45 m
Voltage / phase	380V three-phase or 525V three-phase, by option
Power	37kW (50HP), 2-pole, about 2900 rpm
Inlet / outlet	100 mm suction flange / 80 mm delivery flange
Nominal impeller	200 mm
Self-priming	No, prime the pump before starting
Duty cycle	Continuous
Fluid compatibility	Clean or slightly aggressive water
Net weight	295 kg
Shipping weight	320 kg
Dimensions	1250 x 450 x 520 mm

Description

Overview

The DZA(S) 100-80-200 is a 37kW stainless steel end-suction pump set: a 304 stainless steel pump end already fitted to its 37kW (50HP) electric motor. It moves up to about 200 m³/h (3333 L/min) against a maximum head of 63 m, which makes this 37kw stainless end-suction pump a practical choice for continuous clean-water duty.

Flanges are 100 mm on suction and 80 mm on delivery, with a 200 mm nominal impeller. It works best around 140 m³/h at 55 m. Add the lift to the highest outlet plus about 1 m per 10 m of pipe, then check the head at your flow. Unsure? Send us your flow, lift and pipe length and we will size it for you.

Key features

304 stainless steel casing and impeller, suited to clean or slightly aggressive water
Complete set with a 37kW (50HP) 2-pole motor, about 2900 rpm
100 mm suction and 80 mm delivery flanges
Maximum head 63 m, about 6.3 bar with the valve closed
Built for continuous duty

Options

Choose your motor voltage when you order. The pump end is the same in every option.

With 380V three-phase motor (code 15070112), R 82,664: needs a three-phase supply and a suitable starter and overload.
With 525V three-phase motor (code 15070113), R 82,664: needs a three-phase supply and a suitable starter and overload.

Where it works

Typical jobs are farm and orchard irrigation, dam and reservoir transfer, building water supply, HVAC and cooling-water circulation, and general industrial water. Mpumalanga coal-belt water circuits and big Free State irrigation schemes can use it for high-volume transfer at higher head. Need only the pump end? See the DZA(S) 100-80-200 37kW bareshaft pump and the stainless steel end-suction pumps range, or the DZA(S) 100-80-200 30kW pump set with motor.

What’s in the box

1 x DZA(S) 100-80-200 304 stainless steel pump end, fitted to its 37kW motor
Motor voltage as selected: 380V three-phase or 525V three-phase

Delivery and warranty

Kamano delivers with its own trucks from Polokwane to all nine provinces in 1 to 3 days, including Upington, eMalahleni, Tzaneen, Mahikeng, Richards Bay and Welkom. Delivery is free on orders of R20,000 or more (VAT incl.). At 320 kg this item is over 100 kg, so delivery is on quotation. Ask us for the warranty terms on this model.

Questions about this product

Which motor voltage should I choose for the DZA(S) 100-80-200 37kW set?

Pick the voltage that matches your supply. This set comes as 380V three-phase R 82,664, 525V three-phase R 82,664 (VAT incl.). The 380V and 525V motors need a three-phase supply and a suitable starter and overload. The pump end is the same in every option.

How much water will the 37kW DZA(S) 100-80-200 pump and how high?

It is rated up to about 200 m³/h (3333 L/min) and 63 m with the valve closed. It works best around 140 m³/h at 55 m, and at 200 m³/h it still gives 45 m. Add about 1 m of head for every 10 m of pipe and fittings when you size it.

Can I buy the DZA(S) 100-80-200 37kW pump end without the motor?

Yes. The same pump end is sold as a bareshaft stub shaft pump, part code 15070100, for coupling to your own motor or engine. See the DZA(S) 100-80-200 37kW bareshaft pump listing, or ask us to quote a matching motor.

Do you deliver the 37kW stainless pump set to eMalahleni?

Yes. Kamano delivers with its own trucks from Polokwane to all nine provinces, normally in 1 to 3 days, including eMalahleni and Tzaneen. At 320 kg it is over 100 kg, so we quote the delivery for you, and delivery is free on orders of R20,000 or more (VAT incl.).
