DL8-60 2.2kW Vertical Multistage Pump, 12 m³/h, 62 m Head

Description

Overview

The DL8-60 is a vertical multistage centrifugal pump end that delivers up to 62 m of head at a maximum of 12 m³/h, built around a stainless steel impeller stack and sized for a 2.2kW motor. At this head it suits borehole water supply, rainwater harvesting, domestic pressure boosting, garden irrigation and small rural water schemes. The listing is for the wet end only, so you choose and buy the motor separately, matched to your supply voltage.

Choose by the head your site needs, not by motor size alone. If the DL8-60 is more than you need, look at the DL8-40 1.5kW multistage pump; if it falls short, the DL8-110 4kW multistage pump gives more head. See all of our vertical multistage pumps for the rest of the range.

Key features

• Up to 62 m of head and 12 m³/h maximum flow
• Sized for a 2.2kW motor on 3 phase 380 V 50 Hz, with 220 V and 525 V motor options available
• Vertical multistage construction with a stainless steel impeller stack
• Compact upright footprint that suits pump sheds and plant rooms
• Wet end only, so the motor can be matched to your site voltage

Where it works

Typical jobs are a borehole supply line, a rainwater tank feed, a smallholding irrigation line or a domestic booster set. In the Western Cape it is a common fit for vineyards and orchards around George and Cape Town, where water has to climb a slope or run through a long pipe.

What’s in the box

• 1 x DL8-60 vertical multistage pump end
• Motor not included, sold separately

Delivery and warranty

Kamano delivers with its own trucks from Polokwane to all nine provinces in 1 to 3 days, including Cape Town, Durban, Gqeberha, Bloemfontein, Polokwane and Mbombela. Delivery is charged by total order weight, and at about 18 kg this pump sits in the up to 30 kg band, charged at R550. Free delivery applies to orders of R20,000 or more, VAT incl. Warranty: Ask us for the warranty terms on this model.
