10SP160/3 10-inch Borehole Pump, 37kW, 103 m Head

Description

Overview

The 10SP160/3 is a 10-inch stainless steel multistage submersible borehole pump (37 kW class). It lifts water up to 103 m at shut-off and still delivers 74 m of head at 2,000 L/min (120 m³/h). Peak flow is 216 m³/h, so it belongs on high-yield boreholes.

It is part of the 10SP160 range, a family with a nominal flow of around 160 m³/h, and it runs on three-phase power at 380 V or 525 V. See Options for the set and pump-end choices.

To size it, add your pumping water level, the lift to your tank and about 10% for pipe friction, then check the pump’s head at your flow beats that total. Get the yield-test result first, or the pump may run the borehole dry.

Key features

• Maximum head 103 m, maximum flow 216 m³/h, duty point 120 m³/h at 74 m.
• Needs a borehole with an internal diameter of at least 250 mm.
• Motors above 30 kW need a soft starter, star-delta panel or VSD sized by your electrician. None is included.

Options

• 380 V set, R 65,952: 10SP160/3 pump end with a 45 kW 380 V three-phase water-filled 8-inch motor, no starter panel.
• 525 V set, R 72,568: 10SP160/3 pump end with a 45 kW 525 V three-phase water-filled 8-inch motor, no starter panel or VSD.
• Pump end only, R 13,248: the 10SP160/3 wet end alone, to replace a worn pump end on an existing 37 kW 8-inch motor.

Oil-filled motors are sealed and rated 25 bar. Water-filled motors are rated 35 bar and can usually be rewound, which makes repairs cheaper on bigger sizes.

Where it works

Industrial and agricultural water supply in the Northern Cape and the Western Cape fruit valleys, where boreholes run deep. At 103 m shut-off head this is a low-head, high-volume pump, best where the water level is shallow and the volume is big.

What’s in the box

• 10SP160/3 pump end (all options)
• Water-filled motor, on the set options only
• Not included: starter, cable, rope, delivery pipe, base plate

Delivery and warranty

Kamano delivers with its own trucks from Polokwane to all nine provinces in 1 to 3 days, including Pretoria, Gqeberha, Rustenburg, Pietermaritzburg, Tzaneen and Welkom. At 248 kg it is over 100 kg, so delivery is on quotation, and orders from R20,000 ship free. Large pumps are often supplied to order, so confirm stock and lead time first. Ask us for the warranty terms on this model.
