YB-65 2.5 inch cast iron double-shaft PTO vane pump, 300 to 500 L/min

YB-65 2.5″ PTO Vane Pump, 300 to 500 L/min, Double Shaft

Name: YB-65 2.5" PTO Vane Pump, 300 to 500 L/min, Double Shaft
SKU: KMN-FUEL-0332
Price: 17340.75 ZAR
Availability: InStock

SKU KMN-FUEL-0332

A cast iron 2.5" double-shaft YB-65 PTO vane pump moving 300 to 500 L/min, for bulk diesel transfer. Delivered nationwide.

R17 340,75

300 to 500 L/min through 2.5″ ports
Cast iron, double-shaft drive
Self-priming, 3.45 bar working pressure
51 kg shipping weight

Delivered by our own trucks in 1 to 3 days. R550 / R950 / R1,450 by order weight. FREE on orders of R20,000 or more with code KH027. Delivery details

Specifications

Flow rate	300 to 500 L/min
Max head / pressure	3.45 bar
Voltage / phase	N/A (PTO driven)
Power	On request
Speed	400 to 640 rpm
Inlet / outlet	2.5" (65 mm)
Self-priming	Yes
Duty cycle	On request
Fluid compatibility	Diesel and similar fuel oils; ask us about other fluids
Body material	Cast iron
Shaft	Double
Net weight	47 kg
Shipping weight	51 kg
Dimensions	440 × 250 × 280 mm

Description

Overview

The YB-65 double shaft is a cast iron 2.5 inch PTO vane pump delivering 300 to 500 L/min at 400 to 640 rpm and up to 3.45 bar. It is self-priming, with drive shafts at both ends. Compared with the YB-50, you gain roughly 200 L/min at the top end for about 16 kg more weight.

Specification summary for the yb-65 pto vane pump double shaft: flow rate 300 to 500 L/min; max head / pressure 3.45 bar; speed 400 to 640 rpm; inlet / outlet 2.5″ (65 mm); self-priming Yes; fluid compatibility diesel and similar fuel oils; ask us about other fluids; body material cast iron.

Key features

300 to 500 L/min across the speed range
2.5″ ports for high-volume hose
Cast iron body
Drive shafts on both ends
Self-priming vane design

Where it works

Bulk tankers delivering to farm depots in the Free State, fuel contractors in Mpumalanga and large agricultural co-ops in the Western Cape need to move thousands of litres without hanging around. At 500 L/min a 10,000 L load clears in about 20 minutes. Use 2.5 inch hose to avoid choking the flow. Related kit: YB-80 3″ PTO Vane Pump and 38 mm PTO Pump Hose, Per Metre. Browse more PTO vane pumps.

What’s in the box

YB-65 double-shaft PTO vane pump

Delivery and warranty

Kamano delivers with its own trucks from Polokwane to all nine provinces in 1 to 3 days. Order the yb-65 pto vane pump double shaft online and we ship it from Polokwane. Delivery is charged by total order weight, and free delivery applies on orders of R20,000 or more (VAT incl.). Shipping weight: 51 kg. Ask us for the warranty terms on this model.

Freight is set by the combined weight of your order. This item sits in the 30 to 60 kg band at R950, and extra parts added to the same order only raise the fee if they push the total into the next band. Send us your site address and we will confirm the exact delivery charge before you pay.

Questions about this product

How much faster is the YB-65 than the YB-50?

The YB-65 delivers 300 to 500 L/min, against 150 to 300 L/min for the YB-50. At full speed, that is roughly 200 L/min more, so a 10,000 L tank empties in about 20 minutes instead of 33. It weighs 47 kg net, which is 16 kg more than the YB-50.

Can I mount it on a trailer?

Yes. A 47 kg pump bolts onto a trailer frame or a bakkie bed, provided the mount carries the weight and the PTO drive line is aligned. Use a guarded drive shaft, and fit bolts of the right grade. Ask us for advice on a layout for your tractor.

Do you deliver to Richards Bay and what does it cost?

Yes, we deliver to all nine provinces on our own trucks, normally in 1 to 3 days from Polokwane. This item ships at 51 kg, which is the 30 to 60 kg band: R950 if it is the only item in the order. Orders of R20,000 or more VAT incl. ship free, so adding 2.5 inch hose and couplings can make freight free.

Nationwide delivery from Polokwane

Delivered to all nine provinces in 1 to 3 days

We deliver the YB-65 2.5" PTO Vane Pump, 300 to 500 L/min, Double Shaft with our own trucks to Johannesburg, Pretoria, Cape Town, Durban, Gqeberha, Bloemfontein, Polokwane, Mbombela, Mokopane, Mahikeng, Rustenburg, Secunda, Stellenbosch and East London, and to farms, mines and sites in between. This item ships in the R950 delivery band (30 to 60 kg). Orders of R20,000 or more deliver free with code KH027.
