40 µF 450 V run capacitor for a 2 HP submersible turbine pump

40 µF Run Capacitor for 2 HP Submersible Turbine Pump

Name: 40 µF Run Capacitor for 2 HP Submersible Turbine Pump
SKU: KMN-FUEL-0343
Price: 401.63 ZAR
Availability: InStock

SKU KMN-FUEL-0343

A 40 µF, 450 V run capacitor for the motor of a 2 HP submersible turbine pump, delivered across South Africa from Polokwane.

R401,63

Replacement run capacitor for a 2 HP turbine pump motor
40 µF with ±5% tolerance
450 V voltage rating
Compact at 50 × 50 × 150 mm and 0.2 kg

Delivered by our own trucks in 1 to 3 days. R550 / R950 / R1,450 by order weight. FREE on orders of R20,000 or more with code KH027. Delivery details

Specifications

Type	Motor run capacitor
Capacitance	40 µF ±5%
Voltage rating	450 V
Fits	2 HP submersible turbine pump motor
Duty cycle	Continuous run (motor run type)
Net weight	0.2 kg
Shipping weight	0.3 kg
Dimensions	50 × 50 × 150 mm

Description

Overview

This 40 µF, 450 V run capacitor is the replacement part for the motor of a 2 HP submersible turbine pump. When the capacitor weakens, a single-phase pump motor struggles to start or hums and trips, and a forecourt can lose fuel sales until it is swapped. Keep one on hand with the 2 HP pump motor spares. It is a different value from the 25 µF part used on the 1.5 HP pump, so order by pump rating.

Key features

40 µF capacitance, ±5% tolerance
450 V voltage rating
Made for the 2 HP submersible turbine pump motor
Compact body, 50 × 50 × 150 mm
Light at 0.2 kg and easy to stock

Where it works

Service station owners and pump technicians in Gauteng, KZN and the Western Cape keep a spare for emergency call-outs, and mine fuel bays in Mpumalanga and Limpopo do the same for their bulk tanks. Fleet depots running buried diesel tanks find it cheaper to hold a capacitor than wait on a courier. See the submersible turbine pump range for heads and motors, or the 25 µF capacitor if you run the smaller pump. Isolate the power and discharge the old unit before you swap it.

What’s in the box

40 µF, 450 V run capacitor

Delivery and warranty

Kamano delivers with its own trucks from Polokwane to all nine provinces in 1 to 3 days. Delivery is free on orders of R20,000 or more (VAT incl.). This item ships at 0.3 kg, which puts it in our lowest delivery band of R550 for orders up to 30 kg. Ask us for the warranty terms on this model.

Questions about this product

Can I use this on a 1.5 HP pump?

No. This 40 µF capacitor is matched to the 2 HP motor. The 1.5 HP motor uses a 25 µF part, and a wrong value can overheat the winding or leave the pump short of starting torque. Check the rating plate on your motor, or send it to us, and we will confirm the correct capacitor.

How often does a pump capacitor need replacing?

There is no fixed interval. Capacitors age with heat and starting cycles, and a busy forecourt pump may need one sooner than a farm tank. Replace it when the pump hums, starts slowly or trips, and a meter shows the capacitance has drifted outside 40 µF plus or minus 5 percent.

How much is delivery for a small part like this?

At 0.3 kg the capacitor sits in our lowest band, R550 for orders up to 30 kg. It costs nothing extra if you add it to a larger order under that weight, and orders of R20,000 or more (VAT incl.) ship free. Our own trucks reach all nine provinces from Polokwane in 1 to 3 days.

Nationwide delivery from Polokwane

Delivered to all nine provinces in 1 to 3 days

We deliver the 40 µF Run Capacitor for 2 HP Submersible Turbine Pump with our own trucks to Johannesburg, Pretoria, Cape Town, Durban, Gqeberha, Bloemfontein, Polokwane, Mbombela, Klerksdorp, Tzaneen, Mokopane, Kimberley, Welkom and Secunda, and to farms, mines and sites in between. This item ships in the R550 delivery band (up to 30 kg). Orders of R20,000 or more deliver free with code KH027.
