FMC-50 2 inch rotary vane positive displacement flowmeter with mechanical register

FMC-50 Rotary Vane PD Flowmeter, 2″ (DN50), 38-380 L/min

Name: FMC-50 Rotary Vane PD Flowmeter, 2" (DN50), 38-380 L/min
SKU: KMN-FUEL-0069
Price: 42997.50 ZAR
Availability: InStock

SKU KMN-FUEL-0069

A 2" rotary vane positive displacement flowmeter for custody transfer of petrol, diesel and paraffin at depots and tanker bays, delivered free from Polokwane.

R42 997,50

±0.2% accuracy with repeatability of 0.07% or better
Rated for petrol, diesel, paraffin, jet fuel and fuel oils
2″ (DN50) connections, 38-380 L/min, 10 bar
Mechanical register ready for a ticket printer or pulser

Delivered by our own trucks in 1 to 3 days. R550 / R950 / R1,450 by order weight. FREE on orders of R20,000 or more with code KH027. Delivery details

Specifications

Meter type	Rotary vane, positive displacement
Model	FMC-50
Flow range	38-380 L/min
Accuracy	±0.2%
Repeatability	0.07% or better
Connection size	2" (DN50)
Max pressure	10 bar (150 psi)
Material	Cast aluminium alloy
Display type	Mechanical register, ticket printer and pulser optional
Suitable fluids	Petrol, diesel, paraffin, jet fuel, fuel oils
Net weight	40 kg
Shipping weight	49 kg
Dimensions	520 × 240 × 420 mm

Description

Overview

The FMC-50 is a 2″ rotary vane positive displacement flowmeter for measuring refined fuel where every litre is money changing hands. Sliding vanes in a rotor sweep fixed pockets of fuel through the cast body, which gives ±0.2% accuracy and repeatability of 0.07% or better between 38 and 380 L/min.

It handles petrol as well as diesel, paraffin, jet fuel and fuel oils, and runs at up to 10 bar. The mechanical register can take a ticket printer for delivery dockets or a pulser for remote reading. At around 40 kg it is a two-person lift, so plan a solid pipe support on either side.

Key features

Rotary vane element for custody transfer accuracy of ±0.2%
Repeatability of 0.07% or better
2″ (DN50) connections, 10 bar working pressure
Suits petrol, diesel, paraffin, jet fuel and fuel oils
Register accepts ticket printer and pulser add-ons

Where it works

A positive displacement flowmeter of this class sits on loading arms and tanker offloading points: fuel distributors in KZN, depot operators along the N1, mines receiving bulk diesel in Limpopo, and airstrips handling jet fuel. Fit an inlet strainer and air eliminator ahead of it, because air and grit are what upset accuracy on bulk lines. For larger flows, step up to the FMC-80 3″ flowmeter, or compare with the M-100 4″ bulk flowmeter. More options sit in our bulk flowmeter range.

What’s in the box

FMC-50 2″ rotary vane flowmeter with mechanical register

Delivery and warranty

Kamano delivers with its own trucks from Polokwane to all nine provinces in 1 to 3 days. The FMC-50 meter ships at about 49 kg, which puts it in the 30 to 60 kg band (R950). At this price it already qualifies for free delivery, which applies to every order of R20,000 or more. Ask us for the warranty terms on this model.

Questions about this product

Can the FMC-50 meter petrol from a tanker?

Yes. Rotary vane meters in this family are rated for refined fuels, including unleaded petrol, diesel, paraffin, jet fuel and fuel oils. For petrol work, plan the full installation with an air eliminator, strainer and correctly rated electrical add-ons, and have the meter verified on site before you use it for invoicing.

Can I print a delivery slip from this meter?

Yes. The mechanical register accepts a ticket printer, so your driver can hand the customer a printed docket for each delivery. A pulser can also be added to feed a fuel management system or remote display. Tell us what you want to connect and we will quote the right add-ons with the meter.

Do you deliver to Richards Bay, and what does it cost?

Yes. Our own trucks run from Polokwane to all nine provinces, normally in 1 to 3 days, and Richards Bay is on the route. The FMC-50 meter weighs about 49 kg packed, so on its own it falls in the 30 to 60 kg band (R950). Because the price is above R20,000, delivery on this order is free.
