DL64-40 Vertical Multistage Pump, 22 kW, 80 m³/h, 107 m Head

Description

Overview

The DL64-40 is a vertical multistage centrifugal pump end for water, rated for up to 80 m³/h and 107 m of head with a 22 kW motor. Kamano supplies it as the wet end only, so you match the motor to your own supply.

This is the full-head version in its frame size, and the -1 and -2 models in the DL64-40 frame give a little less head. If your duty changes, compare it with the DL64-40-2 18.5 kW multistage pump or the DL64-20 11 kW multistage pump.

Key features

• Maximum flow 80 m³/h and maximum head 107 m.
• Rated for a 22 kW motor on 3-phase 380 V, 50 Hz, with 220 V and 525 V motor options available.
• Vertical multistage layout with a stainless steel impeller stack.
• Pump end only: the motor is sold separately, and we can quote a complete pump and motor package sized to your voltage and duty.
• Sits in the DL64 range alongside pumps from 7.5 kW up to 45 kW, all at 80 m³/h maximum flow.

Where it works

The DL64-40 suits high-rise building water supply, industrial process water, large-scale agricultural irrigation, mine dewatering support and fire-protection backup systems. Across North West mining and agricultural sites it handles process water and irrigation supply. If your water carries grit or other abrasives, tell us first so we can check the pump is suitable.

What’s in the box

• DL64-40 vertical multistage pump end (wet end)
• Motor not included, sold separately

Delivery and warranty

Kamano delivers with its own trucks from Polokwane to all nine provinces in 1 to 3 days, including Welkom, Klerksdorp, Johannesburg, Pretoria, Cape Town and Durban. The DL64-40 ships at about 70 kg. As the price is over R20,000 VAT incl., delivery is free. Free delivery applies to orders of R20,000 VAT incl. or more. Browse the full multistage pumps range, or ask us to quote the motor and a complete set. Ask us for the warranty terms on this model.
