220V Diesel Pump Kit, 60 L/min, Clear Dirt Filter, Wall Plate

Description

Overview

This 220v diesel pump with filter is a cast-iron 60 L/min transfer pump and a transparent-bowl dirt filter, assembled on a steel wall plate with a 4 m outlet hose and manual nozzle. The 10 micron element stops grit and tank scale on the way out, so machines get clean fuel every time.

The clear bowl lets anyone on site see dirt and water collecting, which makes drain-down part of the daily routine instead of a job that only gets done after a breakdown. The filter is rated to 100 L/min, well above the pump output, so it does not choke the flow.

Key features

• Single-phase 220V pump, 0.60 kW, 20 to 60 L/min
• Transparent-bowl filter with 10 micron element
• Filter rated to 100 L/min, so it does not hold the pump back
• Up to 3 bar, 1 inch BSP connections
• 4 m outlet hose with manual nozzle

Where it works

Construction yards on the East Rand, quarries and municipal plant depots often draw diesel from older steel tanks that shed rust, and a 220v diesel pump with filter is the simple fix. Farms in the Free State and Limpopo use it at the shed tank where fuel can sit for months between harvests. For a case-housed kit with a meter, see the 220V kit with auto-stop nozzle, or add a retractable hose reel to keep the hose tidy. More in diesel pumps and accessories.

What’s in the box

• Wall-mount plate with 220V 60 L/min pump fitted
• Transparent-bowl dirt filter with 10 micron element
• 4 m outlet hose
• Manual diesel nozzle

Delivery and warranty

Kamano delivers with its own trucks from Polokwane to all nine provinces, normally in 1 to 3 days. This item ships at 16.2 kg, which puts it in the up to 30 kg band at R550. Orders of R20,000 or more (VAT incl.) travel free. Ask us for the warranty terms on this model.
