Piusi automatic shut-off diesel nozzle with 24 mm spout and 1 inch swivel inlet

Piusi Automatic Diesel Nozzle, 24 mm Spout, 70 L/min, 1″ Swivel Inlet

Name: Piusi Automatic Diesel Nozzle, 24 mm Spout, 70 L/min, 1" Swivel Inlet
Brand: Piusi
SKU: KMN-FUEL-0036
Price: 1844.85 ZAR
Availability: InStock

SKU KMN-FUEL-0036

A genuine Piusi automatic shut-off nozzle with 24 mm spout and 1" swivel inlet, for spill-free diesel filling up to 70 L/min, delivered from Polokwane.

R1 844,85

Clicks off on its own when the tank is full
Swivel inlet stops the hose kinking
Up to 70 L/min, 24 mm spout
1″ BSP female inlet, aluminium body, Viton seals

Delivered by our own trucks in 1 to 3 days. R550 / R950 / R1,450 by order weight. FREE on orders of R20,000 or more with code KH027. Delivery details

Specifications

Flow range	Up to 70 L/min
Accuracy	N/A (nozzle, not a meter)
Connection size	1" BSP female swivel inlet
Max pressure	On request
Material	Aluminium body, Viton seals
Display type	N/A (no display)
Spout diameter	24 mm
Shut-off	Automatic
Fluids	Diesel and petrol
Net weight	1.5 kg
Shipping weight	1.7 kg
Dimensions	On request

Description

Overview

This Piusi automatic nozzle is an aluminium-bodied shut-off nozzle with a 24 mm spout and a 1 inch BSP female swivel inlet. It handles up to 70 L/min and closes by itself when fuel reaches the spout tip, so tanks do not overflow.

Upgrading from a manual nozzle is one of the cheapest ways to cut fuel loss at a busy fuel point. Operators can fill without holding the trigger the whole time, and the swivel inlet lets the hose turn freely instead of twisting. Seals in Viton resist diesel and petrol, and the aluminium body is light enough that operators do not tire on long fills at the start of a shift.

Key features

Automatic shut-off when the tank is full
Flow up to 70 L/min, suits most 12V and 220V transfer pumps
24 mm spout fits truck and tractor filler necks
1 inch BSP female swivel inlet
Aluminium body with Viton seals, for diesel and petrol

Where it works

A Piusi automatic nozzle is standard kit on bowsers and fixed fuel points at Gauteng transport depots, mine fuel bays in Mpumalanga and farm sheds in the Free State. Anywhere one tank feeds many machines, it pays for itself in spills avoided. Pair it with a 12V 40 L/min pump box for a mobile setup, or replace the hose at the same time with a 24 m roll of 20 mm diesel hose. See more diesel pumps and accessories.

What’s in the box

Piusi automatic shut-off nozzle with 24 mm spout

Delivery and warranty

Kamano delivers with its own trucks from Polokwane to all nine provinces, normally in 1 to 3 days. This item ships at 1.7 kg, which puts it in the up to 30 kg band at R550. Orders of R20,000 or more (VAT incl.) travel free. Ask us for the warranty terms on this model.

Questions about this product

Will it fit my 1 inch diesel hose?

Yes, if your hose ends in a 1 inch BSP male fitting. The nozzle has a 1 inch BSP female swivel inlet that screws straight on. For 20 mm or 25 mm hose without a threaded end, you will need a hose tail and clamp. Ask us and we will send the right fitting.

Will the nozzle shut off on a slow 12V pump?

Automatic nozzles need enough flow to work the shut-off mechanism. Most 12V pumps of 40 L/min or more are fine. On very slow flows, or with a long, narrow hose that chokes delivery, the nozzle may not trip reliably, so keep an eye on the fill.

How much is delivery to Witbank?

This nozzle ships at 1.7 kg, so it falls in the up to 30 kg band at R550 to eMalahleni or anywhere else in South Africa. Our own trucks leave Polokwane and usually arrive in 1 to 3 days. Orders of R20,000 or more including VAT are delivered free.
