YBF-80 220V Explosion-Proof Fuel Pump, 1 Inch, 80 L/min

Description

Overview

The YBF-80 with 1 inch ports is a 220V explosion-proof vane pump that moves 70 to 80 L/min of petrol, diesel, paraffin or solvents. It is the lighter version of the 1.5 inch model, with a 750 W motor and the same continuous (S1) duty rating, so it can run for long periods without a rest. It suits steady dispensing and tank-to-tank work.

Need more flow? The YBF-80 with 1.5 inch ports delivers up to 150 L/min. A 12V alternative is the Cube60 12V fuel transfer pump. All are in fuel transfer pumps.

Key features

• Explosion-proof 750 W motor
• Continuous (S1) duty cycle
• 1 inch BSPT inlet and outlet
• Head of 5 to 10 m, suction lift of 3 to 5 m
• Motor speed 1440 or 1730 rpm, cast iron body
• Mounted in a protective frame with a roll cage

Where it works

Small forecourts and fuel stores in Limpopo and the Free State use a 1 inch explosion proof fuel pump for steady dispensing. Workshops in Gauteng and KZN move petrol and diesel with it, and farms and mines use it where mains power is available and volatile fuel is stored.

What’s in the box

• YBF-80 220V explosion-proof pump with motor
• Protective frame (fitted)

Delivery and warranty

Kamano delivers with its own trucks from Polokwane to all nine provinces in 1 to 3 days. Delivery is free on orders of R20,000 or more (VAT incl.). This pump ships at 32.2 kg, which falls in the 30 to 60 kg band at R950. Ask us for the warranty terms on this model.
