Vega DL5-260 vertical multistage pump wet end, 4 kW class, 168 m head

Vega DL5-260 Multistage Pump Wet End, 4 kW, 168 m Head

Name: Vega DL5-260 Multistage Pump Wet End, 4 kW, 168 m Head
Brand: Vega
SKU: KMN-PUMP-0267
Price: 13750.00 ZAR
Availability: InStock

SKU KMN-PUMP-0267

Vega DL5-260 vertical multistage pump wet end, up to 168 m head at 8 m³/h, for farms, homes and light industry, delivered across South Africa.

R13 750,00

Up to 168 m head at 8 m³/h maximum flow
Vertical multistage design with a stainless steel impeller stack
Rated for a 4 kW motor, 3 phase 380 V, 50 Hz
Wet end only, motor sold separately
R 13,750 VAT incl., delivered from Polokwane

Delivered by our own trucks in 1 to 3 days. R550 / R950 / R1,450 by order weight. FREE on orders of R20,000 or more with code KH027. Delivery details

Specifications

Flow rate	Up to 8 m³/h (maximum)
Max head / pressure	Up to 168 m head
Voltage / phase	3 phase 380 V, 50 Hz (220 V, 380 V and 525 V motor options available)
Power	4 kW rated motor (motor sold separately)
Inlet / outlet	On request
Self-priming	No (vertical multistage, prime the pump before starting)
Duty cycle	On request
Fluid compatibility	Clean water
Model	DL5-260
Construction	Vertical multistage centrifugal pump, stainless steel impeller stack
Supplied as	Pump wet end only, no motor
Net weight	32 kg
Shipping weight	34 kg
Dimensions	220 x 220 x 702 mm

Description

Overview

The Vega DL5-260 multistage pump is a vertical wet end that delivers up to 168 m of head at a maximum flow of 8 m³/h.

A stacked stainless steel impeller design keeps the footprint small, which helps in a tight pump room or plant shed. This listing is the wet end only. You fit a motor rated at 4 kW, or ask us to quote a matched motor for your voltage. The standard supply is 3 phase 380 V at 50 Hz, and 220 V, 380 V and 525 V motor options are available.

Head is the lift the pump can add and flow is how much water it moves, and the two trade against each other along the pump curve. Send us your tank position, pipe size and the flow you need, and we will check the DL5-260 against the job before you order. If you need more or less head, compare the Vega DL5-240 multistage pump and the Vega DL5-220 multistage pump.

Key features

Up to 168 m head at 8 m³/h maximum flow
Vertical multistage centrifugal design with a stainless steel impeller stack
Rated for a 4 kW motor on a 3 phase 380 V, 50 Hz supply
Wet end only, so you choose the motor to suit your voltage
Compact vertical footprint for pump rooms, booster sets and plant sheds

Where it works

At 168 m of head and up to 8 m³/h, the DL5-260 multistage pump suits commercial building pressure boosting, reverse osmosis feed water, medium-scale irrigation schemes and general industrial water transfer. Typical sites include office blocks in Gauteng, vineyards in the Western Cape and grain irrigation in the Free State. Browse the full range of multistage pumps to match your duty point.

What’s in the box

Vega DL5-260 vertical multistage pump wet end
Motor not included

Delivery and warranty

Kamano delivers with its own trucks from Polokwane to all nine provinces in 1 to 3 days, including Mbombela, East London, Upington, Mahikeng, Klerksdorp and Cape Town. Delivery fees are set by total order weight. This pump ships at about 34 kg, which falls in the 30 to 60 kg band at R950. Orders of R20,000 or more (VAT incl.) ship free.

Ask us for the warranty terms on this model.

Questions about this product

Does the DL5-260 come with a motor?

No. This is the pump wet end only, built for a 4 kW motor. You can fit your own motor or ask us to quote a matched one for your voltage. Motor options of 220 V, 380 V and 525 V are available, and the standard supply is 3 phase 380 V at 50 Hz, so tell us your supply when you ask.

How much head does the DL5-260 give?

It delivers up to 168 m of head at a maximum flow of 8 m³/h. Head drops as flow rises, so size the pump for the duty point you need rather than the maximum figures. If you tell us your pipe run, lift and required flow, we can confirm that this model suits the job before you order.

Do you deliver the DL5-260 to Bloemfontein?

Yes. We deliver with our own trucks from Polokwane to Bloemfontein and the rest of the country in 1 to 3 days. At about 34 kg, this pump falls in the 30 to 60 kg delivery band at R950. Fees are set by total order weight, and orders of R20,000 or more (VAT incl.) get free delivery.

Can the DL5-260 feed a reverse osmosis plant?

Yes, it is listed for reverse osmosis feed water, commercial building pressure boosting and medium-scale irrigation. Check the duty point against the pressure and flow your plant needs, and tell us your supply voltage. The pump is wet end only, so the motor comes separately, and we can quote one alongside the pump on request.
